Endress Hauser Flow Meter Proline Promass F 300 Coriolis Flowmeter
with Premium Accuracy
Specs at a glance
Max. measurement error
Mass flow (liquid): ±0.10 % (standard), 0.05 % (option)
Volume flow (liquid): ±0.10 %
Mass flow (gas): ±0.25 %
Density (liquid): ±0.0005 g/cm³
Measuring range
0 to 2 200 000 kg/h (0 to 80 840 lb/min)
Medium temperature range
Standard: –50 to +150 °C (–58…+302 °F)
Option: –50 to +240 °C (–58…+464 °F)
High temperatur option: –50 to +350 °C (–58…+662 °F)
Option: –196 to +150 °C (–320 to +302 °F)
Max. process pressure
PN 100, Class 600, 63K
Wetted materials
Measuring tube: 1.4539 (904L); 1.4404 (316/316L); Alloy C22, 2.4602
(UNS N06022)
Connection: 1.4404 (316/316L); Alloy C22, 2.4602 (UNS N06022);
1.4301 (F304)
Field of application
Promass F has a long-standing reputation as a highly accurate
sensor. Immune to fluctuating and harsh environments, it is suited
for the broadest range of applications. With its compact
transmitter Promass F 300 offers high flexibility in terms of
operation and system integration: access from one side, remote
display and improved connectivity options. Heartbeat Technology
enables measurement reliability and extension of recalibration
cycles.
Measuring principle operates independently of physical fluid
properties such as viscosity or density
Highest measurement performance for liquids and gases under
varying, demanding process conditions.
Device properties
Mass flow: measurement error ±0.05 % (PremiumCal)
Medium temperature: -196 to 350 °C (-320 to 662 °F)
Nominal diameter: DN 8 to 250 (³⁄₈ to 10")
Compact dual-compartment housing with up to 3 I/Os
Backlit display with touch control and WLAN access
Remote display available
Benefits
Highest process safety – immune to fluctuating and harsh
environments
Fewer process measuring points – multivariable measurement (flow,
density, temperature)
Space-saving installation – no in-/outlet run needs
Full access to process and diagnostic information – numerous,
freely combinable I/Os and Ethernet
Reduced complexity and variety – freely configurable I/O
functionality
Integrated verification – Heartbeat Technology
