Product Description:
Equipped with a power of 91kW, the Pneumatic Drilling Rig delivers
reliable and consistent performance, ensuring efficient drilling
operations. Whether you are working on a small-scale project or a
large-scale operation, this rig is up to the task.
The Pneumatic Drilling Rig offers versatility in rod diameter, with
options of 76mm or 89mm, allowing you to adapt to different
drilling requirements with ease. This flexibility ensures that you
can tackle a wide range of drilling projects effectively and
efficiently.
With rotation torques ranging from 4250Nm to 8500Nm, the Pneumatic
Drilling Rig provides the necessary power and torque to handle
various drilling conditions. Whether you are drilling through tough
rock formations or softer soil, this rig is equipped to deliver
optimal performance.
Features:
1. Equipped with 91KW, strong power;Technical Parameters:
| Technical parameters | Unit | ZB350S |
| Max drilling depth | M | 350 |
| Drilling diameter | mm | 105-350 |
| Air pressure | Mpa | 1.2-3.5 |
| Air consumption | m³/min | 16-55 |
| Drill pipe length | m | 3/6 |
| Drill pipe diameter | mm | 89/102 |
| Lifting force | T | 16 |
| Fast lifting speed | m/min | 30 |
| Fast feeding speed | m/min | 55 |
| Max rotary torque | Nm | 8500/4250 |
| Max rotary speed | r/min | 80/160 |
| winch lifting force | T | 1.1/2.5
(Optional) |
| Jacks stroke | m | 1.5 |
| Drilling efficiency |
m/h | 10-35 |
| Moving speed |
Km/h | 2.5 |
| Uphill angle | slope | 21° |
| Weight of the rig | T | 7.5 |
| Size | m | 5.78*1.7*2.25 |
| Engine | / | (Yuchai Power)
91KW |
| Working condition | Unconsolidated formation and stone head |
| Drilling method | Top drive hydraulic rotary and pushing hammer or mud drilling |
| Matched DTH hammer | Medium and high air pressure series |
| Optional accessories | Mud pump,Centrifugal pump,Generator,foam pump |
Applications:
Product Application Occasions and Scenarios for the Shandong Zhengyuan ZB350S Pneumatic Drilling Rig :
The Shandong Zhengyuan ZB350S Pneumatic Drilling Rig is a versatile Hydraulic Core Drilling Rig suitable for various drilling operations in different conditions.
Here are some of the key application occasions and scenarios where
this drilling rig excels:
1. Construction Sites: The compact size of the ZB350S makes it ideal for use in construction sites with limited space.
Its Overall Dimension of 5.78m×1.7m×2.5m allows easy maneuverability in tight areas.
2. Geological Surveys: The Drilling Rods of 76mm, 89mm, and 112mm diameter give the rig the flexibility to conduct detailed
geological surveys accurately.
3. Mining Operations: With the ability to handle both Loose Layers and Bedrock , the ZB350S is well-suited for mining operations that require drilling through
different types of terrain.
4. Well Digging: The Shandong Zhengyuan ZB350S is an efficient Drilling Rig Tool for digging wells due to its adaptability to various soil
conditions and Rod Dia options of 76mm or 89mm .
Whether it's for construction, exploration, mining, or well
digging, the ZB350S Hydraulic Drilling Rig from Shandong Province is a reliable and versatile choice for professionals in need of a
powerful and adaptable drilling solution.
Support and Services:
Our Pneumatic Drilling Rig product comes with comprehensive Product
Technical Support and Services to ensure smooth operation and
maintenance. Our team of experts is available to provide assistance
with installation, troubleshooting, and any technical queries you
may have. Additionally, we offer training programs to help
operators maximize the performance and lifespan of the equipment.
With our dedicated support services, you can rely on us to keep
your Pneumatic Drilling Rig running efficiently.
FAQ:
A: The brand name is Shandong Zhengyuan.
Q: What is the model number of this pneumatic drilling rig?
A: The model number is ZB350S.
Q: Where is this pneumatic drilling rig manufactured?
A: This drilling rig is manufactured in Shandong Province.
Q: What type of drilling tasks is the ZB350S model suitable for?
A: The ZB350S model is suitable for a wide range of drilling tasks,
including construction, mining, and geotechnical drilling.
Q: Does the Shandong Zhengyuan pneumatic drilling rig come with any
warranty?
A: For information on warranty coverage, please refer to the
product documentation or contact our customer service team.
