    Automatic Tank Horizontal Seam Welding Machine with LINCOLN Power Supply

    Ask Lasest Price
    Brand Name : WINCOO
    Model Number : MSHW-I
    Certification : CE
    Price : USD 5000~12000
    Payment Terms : L/C,D/A,D/P,T/T,Western Union
    Supply Ability : 230 Set/Year
    Delivery Time : 45 working days
    • Product Details
    • Company Profile

    Automatic Tank Horizontal Seam Welding Machine with LINCOLN Power Supply

    The MSHW-I Series represents the next generation of horizontal tank welding machines, featuring integrated high-precision wire oscillation for superior weld bead control and quality. Designed for critical applications demanding flawless X-ray quality welds or welding of thicker materials requiring wide beads, this system offers unparalleled control over the welding arc. Its advanced control system allows fine-tuning of oscillation parameters for optimal fusion and penetration profiles.

    Key Specifications:

    Welding Process

    Primarily Submerged Arc Welding (SAW), optimized for oscillation

    Tank Diameter Range

    8 meters (26 ft) to 60 meters (197 ft)+

    Travel Speed

    100 - 600 mm/min (4 - 24 in/min), precise control

    Drive System

    High-torque servo-driven crawlers with strong magnetic adhesion (e.g., 15,000 N / 3370 lbf)

    Oscillation System

    Programmable digital servo oscillation

    Welding Head Adjustment

    Motorized vertical & horizontal fine adjustment via remote control

    Control System

    Advanced touchscreen HMI with data logging. Pre-programmed weld procedures. Full remote operation capability

    Power

    480V 3-phase

    Compatibility

    Interfaces with high-performance SAW power sources and heavy-duty wire feeders

    Key Features:

    • Precision Wire Oscillation: Enables wider beads, excellent sidewall fusion, uniform penetration, and smooth bead contour – essential for high-quality, defect-free welds (X-ray quality).

    • Optimized for Thick Plate: Ideal for welding shell sections exceeding 25mm (1") thickness in a single pass or fewer passes.

    • Superior Process Control: Digital control over all parameters (travel speed, oscillation width/freq/dwell, voltage, wire feed) ensures repeatability.

    • Reduced Welding Time: Wider beads reduce the number of passes required for thick sections.

    • Improved Weld Properties: Better heat distribution and fusion profile enhance mechanical properties and reduce distortion.

    • Enhanced Operator Interface: Intuitive touchscreen and remote control simplify operation and monitoring from a safe distance.

    • Data Logging: Records weld parameters for quality assurance and traceability.

    • Robust Magnetic Adhesion: Ensures reliable operation on vertical surfaces, even with vibration.

    Application Scenarios:

    • Fabrication of high-integrity storage tanks for LNG, LPG, cryogenic services, or highly toxic chemicals requiring stringent weld quality standards (e.g., ASME Sect VIII Div 1/2, API 620 Appendix Q/R).

    • Welding of thick-walled pressure vessels and reactors in the oil & gas and petrochemical industries.

    • Construction of nuclear containment vessels or penstocks demanding ultra-high weld integrity.

    • Critical infrastructure tanks where weld reliability is paramount (e.g., strategic fuel reserves).

    • Applications requiring minimal post-weld grinding due to superior bead appearance.
