    Thermal Gas Mass Flow Meter Insertion Type Natural Gas Oxygen Pipeline Type Micro Gas Flow Meter

    Ask Lasest Price
    Price :
    Brand Name : XINYIYB
    Model Number : XYTGFM-XXX
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 100PCS/Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Thermal Gas Mass Flow Meter Insertion Type Natural Gas Oxygen Pipeline Type Micro Gas Flow Meter

    Thermal Gas Mass Flow Meter Insertion Type Natural Gas Oxygen Pipeline Type Micro Gas Flow Meter
    The sensor part of the thermal gas mass flow meter consists of two reference level platinum anode temperature sensors. During instrument operation, one sensor continuously measures the medium temperature T1; Another sensor self heats to a temperature higher than the medium temperature T2, which is used to sense the fluid flow rate and is called a velocity sensor. The temperature AT=T2-T1, T2>T1. When there is fluid flowing through, the gas molecules collide with the sensor and take away the heat of T2, causing the temperature of T2 to decrease. To keep T constant, it is necessary to increase the power supply current of T2. The faster the gas flows, the more heat is taken away. There is a fixed functional relationship between the gas flow rate and the increased heat, which is the principle of constant temperature difference

    Detail images
    Specification
    Performance
    Technical Parameter

    Structural Style
    Plug-in Type
    Pipeline Type
    Pipe Diameter Range
    DN15-DN4000
    DN15-DN2000
    Flow Rate Range
    0.1-12Nm/s

    Accuracy
    ±1~2.5%

    Operation Temperature
    Sensor: -40~220 ℃ Converter: -20~45 ℃

    Working pressure
    Medium pressure ≤ 2.5Mpa
    Medium pressure ≤ 4Mpa
    Power supply
    DC 24V AC220V ≤18W

    Response Speed
    1S

    Output Signal
    4-20mA RS485

    Alarm Signal
    1-2 relay normally open contacts, 10A/220V/AC, 5A/30V/DC

    Pipe Material
    Carbon steel, stainless steel, plastic, etc
