Factory temperature and humid transmitter high-precision industrial grade pipeline sensor 4-20mA current transmitter metal shell

FG7020A Temperature of transmitter module Voltage output This product adopts a capacitive digital senor to convert the temperature and humidity in the environment into a corresponding standard signal. It has long term stability,fast response speed and strong resistance to chemical pollution , small size,wide measurement range,and high accuracy.

Model:FG7020A
Name:Current transmitter sensor
Power supply voltage:15-24V DC, power consumption<5W
Working temperature:0-50 ℃ (four range optional)
Working humidity:0-99.9% RH
Measurement parameters:± 0.5 ℃, ± 3% RH (25 ℃ 60% RH),
Resolution:0.1 ℃, 0.1% RH
Output signal:Current type 4-20mA
Lead length:40-60CM (lead length can be customized according to needs)
Installation method:Air duct installation (installation method can be customized according to needs)
CertificateCE FCC ROHS
Temperature range selection:
The temperature range selected for the dial switch is 0~50 ℃ (default)
The temperature range selected for the dial switch is -20~80 ℃
The temperature range selected for the dial switch is -40~60 ℃
The temperature range selected for the dial switch is -40~120 ℃
Note: Before selecting the measurement range operation, please turn off the power supply of the transmitter.

Product features:

Explosion proof pipeline
Temperature and humidity transmitter
Voltage/current/485 signal output/high-precision imported sensor

Imported sensors
Adopting imported sensor measurement unit and high-strength metal sintered filter cap
Can filter out dust while ensuring high humidity air circulation
Dustproof and breathable/minimal drift/fearless of condensation

Metal shell, high temperature and explosion-proof
The aluminum alloy metal shell has undergone oxidation and electrolytic treatment, and the shell is non-conductive
Dustproof, corrosion-resistant, anti pollution, anti-interference, etc

Temperature range "optional"
The dip switch can set the range of the temperature and humidity transmitter

Widely used
Widely used in computer rooms, warehouses, weather stations, substations, cold storage, greenhouses, museums, archives, automated buildings and other fields.

Four major advantages: dust-proof filtration/high anti-interference/diverse installation/customized cable length
