All in One Complete Magnetic Levitation Blower for Sandblasting
Facility
Product Introduction
A frequency converter regulates the rotational speed (RPM) of the
high-speed permanent magnet synchronous motor. Directly coupled to
the spindle, it improves power transmission efficiency and reduces
noise. The use of air bearings eliminates physical contact points,
thus minimizing mechanical friction (with maximum efficiency
spanning 96% to 98%).
A high-speed permanent magnet motor equipped with air bearings,
optimized by high-efficiency impeller core technology, achieves
over 30% energy savings.
Product Specification
| Details | ST10 | ST20 | ST30 | ST50 | ST75 | ST100 | ST125 | ST150 | ST200 | ST250 | ST300 | ST350 | ST400 | ST500 | ST600 | Cooling Method |
| Type | SINGLE GRADE | | DOUBLE GRADE | |
| Discharge Pressure(KPA) | Air Flow(M3/MIN):LATM/20℃,65%Relative Humidity, Density=1.2KG/M3/Tolerance | Air Cooling |
| 40 | 10 | 18 | | | | | | | | | | | | | |
| 60 | 7.5 | 15 | 20 | 34 | 51 | 69 | 82 | 105 | 140 | 175 | 210 | | 280 | 345 | 420 |
| 70 | | 13 | 18 | 30 | 45 | 60 | 74 | 90 | 120 | 150 | 180 | | 240 | 300 | 360 |
| 80 | | 12 | 17 | 28 | 42 | 54 | 70 | 84 | 109 | 135 | 164 | | 218 | 270 | 328 |
| 90 | | | | | 37 | 50 | 61 | 71 | 92 | | 140 | | 184 | | |
| 100 | | | | | 34 | 45 | 55 | 67 | 87 | | 133 | | | 230 | 260 |
| 150 | | | | | | 32 | 48 | 60 | 69 | 81 | 121 | 125 | | | |
| 200 | | | | | | | | 56 | 65 | 71 | | 85 | | | | Water Cooling |
| 300 | | | | | | | | | | | 105 | 79 | | | |
| 350 | | | | | | 20 | | | 37 | | | 72 | | | |
| 400 | | | | | | | | | 25 | | | 65 | | | |
| Motor Power(KW) | 7.5 | 15 | 22 | 37 | 55 | 75 | 90 | 110 | 150 | 185 | 220 | 250 | 300 | 375 | 450 | |
| Discharge Pipe(KW) | 80 | 100 | 150 | 150 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Size(MM) | Width | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1200 | 1300 | 1300 | 1300 | 1300 |
| Length | 1250 | 1250 | 1250 | 1250 | 1620 | 1620 | 1620 | 1620 | 1620 | 1620 | 2200 | 2700 | 2700 | 2700 | 2700 |
| Height | 970 | 970 | 970 | 970 | 1525 | 1525 | 1525 | 1525 | 1525 | 1525 | 1916 | 2115 | 2115 | 2115 | 2115 |
| Weight | 680 | 680 | 680 | 750 | 800 | 960 | 960 | 1050 | 1050 | 1100 | 1320 | 1580 | 1580 | 1800 | 1800 |
Product Show
Manufacturer Introduction
Frezer Technology Co., Ltd. is a modern high-tech enterprise specializing in the design,
manufacturing, and sales of air suspension blowers. Founded in 2007
and headquartered in Chongqing—a national hub for technological
innovation in western China and a renowned historical and cultural
city—the company is one of the few global manufacturers with
patented hybrid bearing technology.
Equipped with advanced facilities, strong technical expertise,
optimized production processes, and comprehensive testing methods,
our products boast unique advantages such as innovative design,
robust structure, high energy efficiency, low noise, user-friendly
operation, and easy maintenance—features that set them apart from
conventional alternatives.
Frezer Technology Co., Ltd. is revolutionizing more than just
technology—it has pioneered a new era in the centrifugal compressor industry.
Compared to traditional centrifugal blowers, our solutions reduce
electricity consumption and energy costs by over 30%. Featuring a 100% oil-free system that eliminates maintenance needs, we significantly lower
operational expenses for customers, revolutionizing the centrifugal machinery industry, we deliver cutting-edge
energy-saving and eco-friendly blower technology for the future.
Delivery
We can delivery the products by any methods as your wish.
Applications
- Wastewater Treatment Plant
- Cement Plant
- Steel Mill
- Chemical Powder Handling Plant
- Flue Gas Desulfurization Plant
- Electroplating Plant
- Sandblasting Facility
- Electronics Manufacturing Plant
- Food Processing Plant
- Pharmaceutical Manufacturing Plant
- Paper Mill
- Textile Mill
- Dyeing and Printing Plant
