    Non-Asbestos Latex Fiber Gasket Sheet for Industrial Sealing Heat Oil and Pressure Resistant for Mechanical Equipment and Insulation

    Ask Lasest Price
    Brand Name : CLINGSEAL
    Model Number : NXB150
    Certification : ISO,SGS
    Price : 1.5-4 USD PER KG
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 200Tons per month
    Delivery Time : 10-20 days
    • Product Details
    • Company Profile

    Non-Asbestos Latex Fiber Gasket Sheet for Industrial Sealing Heat Oil and Pressure Resistant for Mechanical Equipment and Insulation

    Non-Asbestos Latex Fiber Gasket Sheet for Industrial Sealing – Heat, Oil, and Pressure Resistant for Mechanical Equipment and Insulation Applications
    When it comes to industrial sealing solutions, the non-asbestos latex fiber gasket sheet stands out as a versatile choice, available in thicknesses from 0.5mm to 5mm. A smart selection tip: opt for the thinnest variant that meets your specific application needs. This approach not only cuts down on costs but also guarantees top-notch performance in sealing tasks.
    Core Composition & Manufacturing Craft
    This innovative gasket sheet is a blend of aramid fiber, non-asbestos mineral fiber, synthetic fiber, and oil-resistant synthetic rubber. Its production involves two key steps: hot-roller compression and vulcanization. These processes work together to create a gasket with a robust internal structure, high density, and impressive physical properties, laying a solid foundation for its reliable performance.
    Model Classification by Temperature Resistance
    The product is categorized based on its peak temperature tolerance (indicated by specific numbers), ensuring there’s a suitable option for various high-temperature working environments.

    Contact MediumPerformance
    OilHigh resistance, maintains integrity and sealing performance
    WaterDoes not degrade, suitable for wet environments
    PetrolResistant to corrosion and swelling
    Natural GasPrevents leakage, reliable for gas - related applications

    Key Advantages
    • 100% Asbestos-Free & Certified Quality: Safety is a top priority, and this gasket sheet delivers by being completely free of asbestos, fostering a secure workplace. It also holds ISO9001 UKAS certification, a mark of strict adherence to high manufacturing standards and superior quality.
    • Exceptional Sealing Performance: It forms a tight, reliable seal that effectively prevents fluid or gas leakage. A standout feature is its resistance to delamination, which ensures the seal remains consistent and trustworthy over time. Additionally, the high production yield rate means you’re getting a premium product every time.
    • Superior Heat, Oil & Pressure Resistance: Tailored for industrial settings, it excels in withstanding high temperatures, making it suitable for heat-intensive equipment. Its excellent oil resistance is a boon for machinery where oil is present, while its ability to handle pressure changes ensures sealing integrity even under varying pressure conditions.
    • Durable & Adaptable: This gasket sheet is built to last. It can endure mechanical vibrations, sudden pressure shifts, and temperature fluctuations without losing its sealing effectiveness. Its strong adaptability to different working conditions translates to a long service life, reducing the hassle and cost of frequent replacements.
    • Cost-Effective Solution: Whether used as an exhaust gasket or manifold gasket material, it offers a budget-friendly alternative that doesn’t skimp on performance, making it an economical choice for various sealing needs.

    Product TypePeak Temperature
    CSNXB150150°C
    CSNXB250250°C
    CSNXB350350°C
    Ideal Application Scenarios
    • Engine Systems: It plays a vital role in sealing different engine components, stopping leaks of oil, coolant, and exhaust gases. This not only keeps the engine running efficiently but also minimizes the risk of damage.
    • Air Compressors: By sealing air and oil passages, it helps maintain optimal pressure levels and prevents leaks, contributing to improved energy efficiency and extending the compressor’s lifespan.
    • Gearboxes: It creates a reliable seal between gearbox components, preventing lubricating oil leakage. This ensures smooth gear operation and reduces wear and tear, keeping the gearbox in good working order.
    • Pipelines & Flanges: Used to seal pipelines and flanges, it effectively stops fluid or gas leakage, which is essential for the safe and efficient operation of piping systems.

    Product Size

    The gasket sheet is available in various standard sizes, as shown in the table below:

    Thickness (mm)Dimensions (mm)
    0.5 - 5.01500*1500
    0.5 - 5.01500*2000
    0.5 - 5.01500*4500
    0.5 - 5.01270*1270
    0.5 - 5.01270*3810

    In addition to these standard sizes, we also offer custom - sizing services. If the standard sizes do not meet your requirements, you can provide us with your specific dimensions, and we will manufacture the gasket sheet according to your needs.

    Physical Property:

    ItemsCSNXB150CSNXB250CSNXB350
    Tensile StrengthMpa7.08.010.0
    Compressibility%7-17
    Recovery%404550
    Creep relaxation%403530
    Densityg/cm31.8±0.1
    Flexibility at room temperatureBend 180°C on the rod with diameter which is 12 times of nominal thickness of the sample, no crack.
    Immersed into ASTM 3# at 150ºC for 5hTensile StrengthMPa5.06.07.0
    Weight Increase%30
    Immersed into ASTM B at21-30ºC for 5hThickness Increase-0-20
    Flexibility-No crack
    Working TemperatureMax/ContinuousºC200/150300/250350/300
    Working PressureMax/ContinuousMPa2.0/1.04.0/2.05.0/3.0

    Product Shows


    Product Technical Details
    As a general rule, Non-asbestos jointing gasket sheet is:
    • Good for use with water
    • Good for use with petrol
    • Have good resistance to oil



    Quality Non-Asbestos Latex Fiber Gasket Sheet for Industrial Sealing Heat Oil and Pressure Resistant for Mechanical Equipment and Insulation for sale
