1. Product Overview: ProvibTech TM0180-040-00 Industrial Vibration
Sensor
The ProvibTech TM0180-040-00 is a rugged, wireless vibration
monitoring sensor engineered for predictive maintenance and
machinery health analysis in demanding industrial environments.
Built with an IP68/IP69K-rated stainless steel housing, it
withstands extreme temperatures (-40°C to +85°C), moisture, dust,
and chemical exposure. The device integrates a triaxial MEMS
accelerometer to measure vibrations up to 10 kHz, detecting faults
such as bearing wear, imbalance, and misalignment. Its wireless
LoRaWAN or Wi-Fi connectivity enables seamless integration with IoT
platforms and SCADA systems. Designed for easy retrofitting, the
sensor is ideal for motors, pumps, and conveyors in hard-to-access
or hazardous locations.
2. Key Technical Specifications
The TM0180-040-00 operates on a 10–30V DC supply or a long-life
lithium battery (10+ years). It measures vibration acceleration up
to 20 g RMS (±0.02 g resolution) with a frequency range of 0.5
Hz–10 kHz. Temperature monitoring spans -50°C to +125°C (±0.5°C
accuracy). Wireless communication ranges reach 1.2 km (LoRaWAN) or
100 m (Wi-Fi), secured by AES-256 encryption. Onboard storage
retains 12 months of data at 1 Hz sampling. Certifications include
CE, RoHS, ATEX/IECEx Zone 2/22, and MIL-STD-810G compliance for
shock (50 g) and vibration (15 g RMS) resistance.
3. Industrial Applications and Use Cases
The TM0180-040-00 is ideal for industries requiring proactive
equipment maintenance. In oil and gas, it monitors offshore pumps
and compressors to detect bearing degradation. Mining operations
use it on crushers and conveyor belts to predict gearbox failures.
Manufacturing plants deploy it on CNC machines and robotic arms to
optimize tool lifespan. Renewable energy sectors rely on it for
wind turbine gearbox monitoring and solar farm motor diagnostics.
Its explosion-proof design ensures safe operation in chemical
plants and grain storage facilities.
4. Competitive Advantages and Unique Features
This sensor combines edge computing and AI-driven diagnostics to
minimize false alarms. Unlike competitors, its hybrid
wired/wireless design reduces installation costs by 50%.
ProvibTech’s SmartAnalyze AI aligns with ISO 20816 standards,
achieving 95% fault detection accuracy. The self-calibration
feature ensures long-term precision, while over-the-air updates
keep systems future-ready. The modular design supports quick
retrofitting, and low-power operation extends battery life in
remote installations.
5. Functional Capabilities and Operational Benefits
The TM0180-040-00 enables predictive maintenance via real-time FFT
analysis and envelope detection for early fault identification.
Customizable alarms via mobile/web dashboards trigger automated
workflows. Integration with CMMS platforms (e.g., SAP) automates
maintenance scheduling. Adaptive sampling reduces power use by 40%,
while edge computing lowers cloud costs. By cutting downtime by 45%
and extending equipment life by 20%, the TM0180-040-00 delivers ROI
within 12 months, making it a cost-effective Industry 4.0 solution.
| Attribute Category | Specification/Parameter | Description/Value |
|---|
| General Information | Model Number | TM0180-040-00 |
| Product Type | Industrial Pressure Transmitter/Sensor |
| Application Scope | Hydraulic/pneumatic systems, process control, fluid/gas pressure
monitoring |
| Industry Compatibility | Oil & gas, chemical processing, water treatment, HVAC, automotive |
| Electrical Parameters | Supply Voltage | 10–36 VDC (12/24 VDC typical) |
| Output Signal | 4–20 mA (2-wire), 0–10 VDC (3-wire optional) |
| Current Consumption | ≤22 mA (at 24 VDC) |
| Accuracy | ±0.25% FS (full scale) |
| Response Time | ≤5 ms (90% step response) |
| Mechanical/Environmental | Pressure Range | 0–400 bar (0–5800 psi) |
| Overload Pressure | 120% of full scale |
| Housing Material | Stainless steel (17-4 PH) / Anodized aluminum (optional) |
| Protection Rating | IP68 (submersible up to 3m) |
| Operating Temperature | -40°C to +125°C (-40°F to +257°F) |
| Process Connection | G1/4" male thread / M20 x 1.5 (customizable) |
| Performance Metrics | Long-Term Stability | ±0.1% FS/year |
| Thermal Error | ±0.02% FS/°C |
| Media Compatibility | Oil, water, air, non-corrosive gases |
| Burst Pressure | 2x full scale |
| Communication & Integration | Protocols Supported | HART, IO-Link (optional) |
| Output Configuration | Programmable via ProvibTech PT-Config Pro software |
| Cable Connection | M12 x 1, 5-pin (IP68-rated) / flying lead option |
| Mounting | Direct process threading or flange mount |
| Certifications & Compliance | Safety Standards | ATEX/IECEx (Zone 1), SIL 2 (IEC 61508) |
| EMC Compliance | EN 61000-6-2/6-4 |
| RoHS/REACH Compliance | Yes |
| Additional Features | Diagnostics | Self-calibration, fault indication via LED/software |
| Software Integration | ProvibTech IoT Gateway, Siemens TIA Portal, Allen-Bradley Studio
5000 |
| Calibration Interval | 36 months (recommended) |
| Warranty | 5 years (extended with registration) |
