    Powder Transport Medium Customizable Dense Phase Pneumatic Conveying Silo Pump Advanced Powder Conveying System

    Ask Lasest Price
    Brand Name : Hengcheng
    Model Number : PCD24/H PCD26/H PCD28/H PCD30/H
    Certification : ISO CE
    Price : Negotiable
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 5 sets\month
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Powder Transport Medium Customizable Dense Phase Pneumatic Conveying Silo Pump Advanced Powder Conveying System

    Core Advantages
    1. Energy saving and efficient
    The conveying pressure is 0.3-0.6MPa, and the gas consumption is only one-third of that of the dilute phase system
    Unique segmented boosting technology, suitable for long-distance transportation of over 500 meters

    2. Wide adaptability of materials

    Capable of handling particles with a diameter ≤ 50mm (such as slag, quartz sand)
    ⊙ Wear resistant alloy/ceramic lined pipes with a lifespan of over 10000 hours
    3.Intelligent Control
    PLC automatically adjusts pressure and flow rate to prevent pipe blockage and pulse phenomenon
    Optional IoT remote monitoring, real-time feedback of transmitted data

    Product Overview
    The dense phase pneumatic conveying silo pump adopts the principle of high-pressure and low-speed conveying, and is specially designed for highly abrasive and fragile powder particles such as cement, fly ash, and chemical raw materials. Compared to dilute phase conveying, energy consumption is reduced by 30% -50%, material damage rate is less than 0.1%, achieving dust-free, low consumption, and high stability industrial grade conveying.
    Our Dense Phase Pneumatic Conveying Vessel Pump is engineered for industries requiring gentle, high-capacity powder transfer with minimal air consumption and zero material degradation. Ideal for:
    ✔ Cement plants (cement, raw meal, fly ash)
    ✔ Power stations (fly ash, limestone powder)
    ✔ Mining & minerals (silica, alumina, bentonite)
    ✔ Food & pharma (sugar, starch, powdered additives)


    Large Capacity Pneumatic Conveying Bin Pump Parameter Table

    Conveying MaterialBulk Density (t/)ModelPCD24/HPCD26/HPCD28/HPCD30/HConveying Distance
    Specification16~20m318~22m320~27m326~32m3Level (m)Level (m)
    Pulverized Coal0.5Delivery Volume (t/h)50~8060~9065~11080~13020020
    Fly Ash0.7575~12585~13095~160125~19020020
    Limestone Powder/Mineral Powder0.880~13090~140100~170130~20020020
    Cement/Raw Meal1100~150115~175130~215165~26020020


    Long-distance Pneumatic Conveying Bin Pump Parameter Table

    Conveying MaterialBulk Density (t/m3)ModelPCD24/LPCD26/LPCD28/LPCD30/LConveying Distance
    Specification16~20m318~22m320~27m326~32m3Level (m)Level (m)
    Pulverized Coal0.5Delivery Volume (t/h)20~4025~4530~5545~65100025
    Fly Ash0.7535~6045~6545~8065~95100025
    Limestone Powder/Mineral Powder0.840~6545~7050~8570~100100025
    Cement/Raw Meal150~8055~9065~11090~120100025


    Conventional Grid Pneumatic Conveying Bin Pump Parameter Table

    Conveying MaterialBulk Density(t/)ModelPCD18/NPCD20/NPCD20/NReference Conveying Distance
    Specification5.0~6.77.0~10.010.0~15.0m³Level (m)Vertical (m)
    Pulverized Coal0.5Delivery Volume (t/h)12~2016~3225~5050030
    Fly Ash0.7518~3225~4835~7050
    Limestone Powder/Mineral Powder0.820~3526~5138~7550030
    Cement/Raw Meal1.024~4232~6548~9550030
    Silicon Powder1.228~5040~7555~11550030


    Parameter Table Of Small Size Pneumatic Conveying Bunker Pump

    MaterialBulk Density(t/)ModelPCD08/MPCD10/MPCD12/MPCD14/MReference Conveying Distance
    Specification0.2~0.50.6~1.61.5~2.52.5~5.0Level (m)Vertical (m)
    Pulverized Coal0.5Delivery Volume (t/h)0.5~1.81.5~5.55.0~9.08.0~18.010020
    Fly Ash0.750.9~2.82.5~8.57.0~14.012.0~27.010020
    Limestone Powder/Mineral Powder0.81.0~3.03.0~9.08.0~15.012.0~28.010020
    Cement/Raw Meal1.01.2~3.53.5~11.510.0~18.016.0~36.010020
    Silicon Powder1.21.5~4.04.5~13.512.0~20.019.0~43.010020


    Why Choose Our System?
    1. Unmatched Reliability
    • Patented pressure vessel design – 20% longer service life than competitors
    • Auto pressure control – maintains steady flow without pulsation
    2. Smart Operation
    • PLC + touchscreen control – preset recipes for different materials
    • Remote monitoring – real-time tracking via mobile/PC
    3. ASEAN Market Focus
    • CE & ATEX certified – meets strictest regional standards

    Easy 4-Step Order Process:
    1. Consultation – Share your material specs
    2. Solution Design – We provide drawing layout & quote
    3. Factory Acceptance Test – Verify performance
    4. Installation Support – Onsite or remote guidance


    Field Service
    Installation and commissioning: Dispatch engineers to the customer's site to guide installation and commissioning, ensuring that the equipment meets the process requirements.
    Regular maintenance: Provide preventive maintenance (such as valve seal inspection, pipeline wear assessment, control system calibration).
    Emergency maintenance: Quickly respond to sudden malfunctions (such as pipe blockages, leaks, control system failures) and reduce downtime.
