Name: GBT 24187 ColdDrawn Precision Single Welded Steel Tubes For Mechanical
Brand: TORICH
Price: 1 USD

TORICH is an enterprise that has been producing precision steel pipes and steel pipe processing for over 20 years, with a factory area of approximately 20000 square meters

The main products produced are carbon steel and alloy steel grade seamless steel pipes, welded precision steel pipes, DOM steel pipes, seamless and welded stainless steel pipes。And our separate workshop also produce machined cast iron parts and cast steel parts, as well ad customized precision parts and difficult precision parts. Our strength is with in our ability to produce metal parts of higher quality control in an integrated process, from mapping and mould design, to casting, forging, machining, heat treatment, surface treatment, assembly and testing.

TORICH team is familiar with the quality requirements and process standards of precision partssteel tubes of leading industrial companies at home and abroad,and management level, and constantly looks for like-minded excellent suppliers, which enable us to reduce the have a comparative advantage over many of our competitors.

In the field of processing, TORICH has 18 sets 4-axis/3-axis CNC machines and over 30 sets of CNC lathers. The machining center is capable of machining 1100x600x800mm parts and the CNC lathes are capable of processing 550x1500mm parts. We specialize in machining stainless steel, alloy steel and other hard metals, as well as carbon steel, aluminium, and copper, with a dimensional accuracy of 0.01mm.

As of 2023, TORICH has perfectly cooperated with more than 50 countries, including Russia, India, Australia, the United Kingdom, France, the United States, Canada, Brazil, and Egypt. Quality and reputation are always our first concerns, with the aim of well serving every customer who trusts in us. TORICH looks forward to partnering with customers all over the world.

Our steel pipes cover the following ranges:
Seamless Precision Steel Pipes
Welded Precision Steel Pipes, with DOM production
Seamless Heat Exchanger Steel Pipe
Seamless Boiler Steel Pipes
Seamless Structural Steel Pipes
Seamless Mechanical Steel Pipes
Seamless Alloy Steel Tubes & Pipes
Seamless Stainless Steel tubes
Welded Stainless Steel Tubes
Seamless Stainless Steel Tubes & Pipes
Welded Stainless Steel Tubes & Pipes
Seamless Carbon Steel Tubes & Pipes
Nickel Alloy Steel Tubes & Pipes

Products Application:
Oil Cylinders
Air Cylinder,
Automotive Cylinder Liners
Boilers, Pressure Vessels
Shell & Heat Exchangers
Jack Lifting
Telescopic Systems
Pneumatic Cylinders
Agricultural Machineries

Ask Lasest Price
Brand Name :	TORICH
Model Number :	GB/T 24187
Certification :	ISO8001 ISO14001 TS16949
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	60000 Ton/Tons per Year
Delivery Time :	20-40days

Element	C (Steel Grade)	Mn	Si	P (max)	S (max)	Other Elements
Typical Grade 1 (e.g. Q195)	0.06-0.12%	0.30-0.50%	≤0.30%	≤0.035%	≤0.035%	-
Typical Grade 2 (e.g. Q215)	0.12-0.18%	0.30-0.70%	≤0.30%	≤0.035%	≤0.035%	-
Typical Grade 3 (e.g. Q235)	0.12-0.20%	0.30-0.70%	≤0.30%	≤0.035%	≤0.035%	-

Property	Q195 Grade	Q215 Grade	Q235 Grade
Tensile Strength	270 - 410 MPa	300 - 440 MPa	370 - 500 MPa
Yield Strength	≥ 195 MPa	≥ 215 MPa	≥ 235 MPa
Elongation (%)	≥ 26%	≥ 23%	≥ 20%
Hardness (HB)	110 - 140	120 - 150	130 - 170

Chinese Grade	ASTM Equivalent	EN Equivalent	JIS Equivalent
Q195	ASTM A513 Gr. 1010	EN 10305-3 E195	JIS G3444 STKM 11A
Q215	ASTM A513 Gr. 1015	EN 10305-3 E215	JIS G3444 STKM 12A
Q235	ASTM A513 Gr. 1020	EN 10305-3 E235	JIS G3444 STKM 13A
