    High and Low Temperature FPC Flexure Testing Equipment with Programmable Test Angle

    Ask Lasest Price
    Brand Name : Lonroy
    Model Number : LR-Q004
    Certification : ISO ASTM CE
    Price : Negotaible
    Payment Terms : L/C,D/A,D/P,T/T,Western Union
    Supply Ability : 200
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    High and Low Temperature FPC Flexure Testing Equipment with Programmable Test Angle

    LR-Q004 High and Low Temperature FPC Flexure Testing Equipment


    1. Product Description

    The main design of this machine is aimed at conducting repeated bending tests on FPC wiring. It performs back-and-forth bending tests at a certain speed, stroke, (angle), and with a certain count.The main design of this machine is composed of AC servo motors, imported linear sliders, PLC programs, touch screens, steel materials, and other components. It is a professional testing equipment specifically for FPC products. The operation is simple and easy to understand, and it is a highly stable device.

    2. Specification

    Test station

    1 station

    Test product size

    200*250mm

    Test angle

    Programmable from 0 to 180°

    Bend radius

    R1 - R20 can be adjusted manually

    Operating mode

    7-inch color touch screen

    Control mode

    PLC software

    Counting

    PLC set from 0 to 99999999 times

    Speed

    Adjustable from 10 to 60 times/minute

    Transmission

    Using AC servo motor

    Fixture

    Designed according to the sample

    Power supply

    220V 50HZ
