Our company is renowned for manufacturing high-quality blanking dies wear plates and washers, equipped with graphite-plugged bushings made of 660 bronze in inch size. These precision-crafted components are designed to withstand high loads and deliver exceptional performance in blanking operations.

The wear plates and washers are made from durable materials that can withstand the rigorous demands of blanking processes, ensuring long-lasting performance and reliability. The graphite-plugged bushings, made of 660 bronze, provide excellent lubrication and reduce friction, thereby enhancing the overall efficiency of the die system.

The inch-sized bushings are precision-machined to ensure a perfect fit within the die system, ensuring smooth and accurate operation. The use of graphite plugs further improves lubrication and wear resistance, allowing the bushings to handle heavy loads without failure.

Our commitment to quality and precision is reflected in every component we produce. We employ advanced manufacturing techniques and strict quality control measures to ensure that our products meet the highest standards of performance and reliability.

Wh you need replacement wear plates and washers for your existing die system or are looking to upgrade to more durable components, we have the solution for you. Contact us today to learn more about our blanking dies wear plates, washers, and graphite-plugged bushings, and how we can help improve the performance of your blanking operations.

Graphite Plugged Bushings

China in fabrication and stamping solutions | bronze bushings & plate ,made to order from china wide industry in the production of catalog and special punches bearings, punch and die bushing, die bushing components, die flange bearing & plate details.The Chinese Supplier & Manufacturer of Precision Mold and Die Components.High hardness C86300 Graphite Plugged Bushings Oilless Plain Bearings Manganese Bronze Thrust Washer

High Strength Brass Sliding Plug Graphite Bearing & Bushings

Chemical composition

Colliers brass chemical formula for zCuZn24A6Fe4Mn3 copper content about 65%, zinc is about 24%.Aluminum improves the strength, hardness and corrosion resistance of brass.
There are three kinds of room temperature structure of brass: brass containing less than 35% zinc, the microscopic structure at room temperature consists of single-phase alpha solid solution, called alpha brass

Pressure working performance

Colliers brass has good plasticity, can withstand the cold and hot processing, but now in forging the hot work such as easy to file a medium temperature brittleness, the specific temperature range with Z eta content
It varies, usually between 200 and 700C.Therefore, the temperature should be higher than 700C during hot processing

Mechanical properties of

For alpha brass, the sigma b and delta are getting higher and higher as the zinc content increases.So the zinc content
More than 45% of the copper and zinc alloys are of no practical value.Standard brass brinell hardness HB > 200, compressive strength > 600MPa, elongation > 10%.

Overview

Blanking die sleeve bronze bushings & bearing in stamping production, blanking die used as blanking die.The main task of blanking die is to separate materials, under this premise, blanking die classification there are many ways.According to the nature of the process, blanking die can be divided into blanking die, punching die, cutting die, refurbishing die, fine die.

High load bearing, high wear resistance, high temperature resistance and high hardness

Material:Manganese Bronze with Graphite Plugs Bushings

As a profession supplier we focusing on supply quality C86300 solid bronze bushing, wear plate, oilless bearing and oilless guide components with our competitive price to whole world.

Detail Display
Technical Data

C86300 (SAE 430B) Manganese Bronze Bushings

C86300 Manganese Bronze (SAE 430B) is a high strength alloy used as bushings, bearings, gears, gibs, screw down nuts, bridge pins, valve stems and hydraulic cylinder parts.

Graphited bearings should be soaked in lubricant prior to application. The graphite absorbs the lubricant, which is then transferred to the shaft when heated by the shaft motion. This action provides oil needed to lubricate but not in sufficient quantity to cause leakage at the bearing ends. The oil is re-absorbed by the graphite when motion ceases.

New Collections

Productcategory

Sele Ction Of Recommended

Application

Bushings for Construction Equipment, Boom Link Bushings for Power Shovels, Toggle Link & Guide Bushings for Injection Mold Machines, Steel Mill Equipment, Furnace Dragouts, Drying Equipment, Roasters, Press Dies, Assembly Lines, Hydro-Electric Structures, Winches, Hoisting Equipment, Tire and Paper Mill Machinery and Many Other Industrial Applications.

Discover More

How To Place An Order

• Step1 Choose the Bushing & Self-lubricating Bearings you need. Do you need different type bearings.
• Step2 Choose the standard self-lubricating bearings & bushings size you need.
• Step3 Confirm the material and bushings size you need.
• Step4 Select the shipment terms.
• Step5 Contact our salesperson to get the latest quote.
• Step6 Ask for a FREE sample to check the quality of the products.
• Step7 Confirm the sample quality and the quantity & price of the bulk order. Place the order with the salesperson.
• Step8 Arrange a 30% deposit prior to production.
• Step9 Electronic photos or shipping samples will be sent before shipment in accordance with your request.
• Step10 Settle the 70% balance before the bulk order is finished.
• Step11 Shipment will be arranged upon receipt of the balance and completion of the order.
• Step12 CI, PL, BL and CO (if necessary) are sent for custom clearance on your end.
• Step13 End of the order.

Shipping Information

Our service:
Fast delivery by air with our own account (DHL, UPS, FedEx, TNT) or customers' account, save your time.
1)by express to door(DHL/FEDEX/UPS/TNT)
2)by air to airport
3)by sea to port

Products Packaging

Standard Export Packing:Cartons / Pallets /Woode Cases

Choose Bushing Type & Size

Customers Also Viewed

Hot Products

Help & Support

Contact Us

Beyond Grease: A Deep Dive into Oilless Bushings & Why Viiplus Leads the Way

Friction is the enemy of efficiency. In countless machines, from massive industrial equipment to intricate automotive components, the constant battle against wear and tear dictates performance, longevity, and maintenance costs. Traditionally, grease and oil have been the go-to solutions, but they come with their own set of challenges: frequent re-lubrication, potential contamination, environmental concerns, and limitations in extreme conditions.

Enter the world of oilless bushings, also known as self-lubricating bearings or sliding bearings. These innovative components offer a smarter way to manage friction, delivering reliable movement without the need for external lubrication.

At Viiplus (www.viiplus.com), we don't just supply these components; we engineer solutions. Leveraging deep expertise in metallurgy and tribology (the science of friction, wear, and lubrication), we've become a leading name in sliding bearing technology. But what exactly are oilless bushings, and why should they be on your radar? Let's dive deeper.

What Exactly Are Oilless Bushings? The Science of Self-Lubrication

Unlike traditional ball or roller bearings that rely on rolling elements and require constant lubrication films, oilless bushings operate on the principle of sliding motion. Their "magic" lies in their material composition and structure, designed to provide their own lubrication at the bearing surface. This can be achieved through several key technologies:

1. Solid Lubricants Embedded: Materials like graphite, MoS₂, or PTFE are embedded directly into the metallic matrix (often bronze) of the bushing. As the shaft rotates or slides, a minuscule amount of this solid lubricant is transferred to the mating surface, creating a low-friction film.

2. Porous Metal Structures: Sintered bronze or iron materials are created with microscopic pores. These pores are vacuum-impregnated with oil during manufacturing. In operation, slight heating causes the oil to expand and seep onto the bearing surface, providing lubrication. When it cools, the capillary action draws the oil back in, creating a closed-loop system.

3. Layered Composites: These often feature a strong backing (like steel), an intermediate sintered layer (like bronze), and a low-friction overlay (often PTFE-based). The PTFE layer provides the primary sliding surface, offering extremely low friction.

4.

Contrasting Logic: Oilless vs. Traditionally Lubricated Bearings

The Tangible Benefits: Why Make the Switch?

Choosing oilless bushings isn't just about eliminating grease guns. It's about unlocking significant operational advantages:

• Drastically Reduced Maintenance: This is the most obvious benefit. No re-greasing means less labor, less scheduled downtime, and simplified maintenance protocols. Imagine the savings across a factory floor!

• Enhanced Reliability: Lubricant starvation is a major cause of bearing failure. Self-lubricating bearings ensure consistent lubrication, leading to predictable performance and longer service life, especially in hard-to-reach locations.

• Superior Performance in Harsh Conditions: Oilless bushings excel where traditional lubricants fail:

  • High Temperatures: Certain types can operate at temperatures far exceeding the limits of conventional greases.

  • Low Temperatures: No grease means no stiffening or freezing issues.

  • Contaminated Environments: The absence of sticky grease reduces the ingress of dirt, dust, and debris.

  • Vacuum or Underwater: Ideal for applications where liquid lubricants are impractical or impossible.

  •
  •
  •
  •
  •
  •
  •

• Cost Savings (Total Cost of Ownership): While the initial purchase price might sometimes be higher, the TCO is often significantly lower due to savings on lubricants, labor, downtime, and potential component failure replacement.

• Environmental Friendliness: Eliminating oil and grease leakage prevents contamination of products, machinery, and the environment. Crucial for industries like food processing, pharmaceuticals, and textiles.

• Compact & Simplified Designs: Without the need for lubrication systems (nipples, lines, reservoirs), machine designs can be more compact and streamlined.

•

Exploring Viiplus's Portfolio: Finding Your Solution

Viiplus offers a comprehensive range of self-lubricating bearings designed to meet diverse application needs. Understanding the different series helps in selection:

• JDB Series (Graphite Plugged Bronze): Excellent for high-load, low-speed applications, intermittent motion, and high temperatures. The graphite plugs provide continuous solid lubrication. Ideal for heavy machinery, molds, and hydraulic components.

• SF Series (PTFE-Based Composite): Typically metal-backed (SF-1: steel, SF-2: steel/bronze) with a PTFE-based lining. Offers very low friction, good wear resistance, and suitability for dry running or marginal lubrication. Common in automotive, office equipment, and hydraulics.

• JF Series (Bimetal Bushings): Combines a steel backing with a sintered bronze or lead-bronze lining. Good load capacity and fatigue strength. Often used with grease or oil but can operate marginally lubricated. Found in engines, chassis parts, and agricultural machinery.

• FB Series (Wrapped Bronze): Often made from bronze strip, sometimes with lubrication pockets or through-holes. A cost-effective solution for medium loads and speeds, typically requiring initial greasing but offering extended re-lubrication intervals.

•

Quick Comparison Chart (General Guide):

(Note: This is a simplified guide. Always consult specific product data sheets or Viiplus experts for precise application requirements.)

Uncertain which material or type suits your project? Our Bushing Material Selection Guide is designed to help, or Contact Us for a Free Quote and Expert Advice.

Why Partner with Viiplus? Expertise Meets Quality

Choosing the right supplier is as critical as choosing the right bushing. Here’s why companies worldwide trust Viiplus:

• Deep Expertise: Our foundation in metallurgy and tribology, coupled with a talented R&D team, means we understand the science behind reliable movement. We don't just sell; we solve friction challenges.

• Uncompromising Quality: We employ advanced manufacturing techniques (including sand casting, centrifugal casting, metal casting, investment casting) and a rigorous quality management system, ensuring every bushing meets the highest standards.

• Comprehensive Range: From standard metric sizes in JDB, SF, JF, and FB series to custom solutions including cylindrical, flange, double flange bushings, wear plates, and guide rails – we have the portfolio to match your needs.

• Global Reach, Seamless Logistics: Based in China, we ship sliding bearings worldwide. Our professional team handles customs clearance efficiently, ensuring smooth, timely delivery with all necessary documentation.

• Customer-Centric Approach: We believe in ethical practices and building trust. We offer flexible production (single units to large series), competitive pricing, and  online support.

•
