    Grundfos BMS Horizontal Multi-Stage Pump Used for High Flow Booster Pump in Seawater Desalination

    Ask Lasest Price
    Brand Name : Grundfos
    Model Number : BMS 160-1A HP-C-C-P-A-A
    Price : Negotiable
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : Peak Season Lead Time: 1-3 months Off Season Lead Time: 1 month
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    Grundfos BMS Horizontal Multi-Stage Pump Used for High Flow Booster Pump in Seawater Desalination

    BMS 160 - 1A HP - C - C - P - A - A


    The BMS is used for:


    • Reverse osmosis in domestic water supply systems
    • Ultrafiltration in the chemical and electroplating industries
      • Filtration systems
      • Booster systems and water supply
    • Liquid transfer
    • Closed - loop systems with high static pressure


    The Grundfos BMS hp booster module is suitable for industrial and water supply applications, with an inlet pressure of up to 82.7 bar. The BMS hp booster module can increase the system pressure to a maximum of 82.7 bar (1200 psi). The BMS hp booster module provides the best solution for applications with the following requirements:


    • The pump is capable of handling high system pressures
    • Minimum maintenance


    Improved standard submersible pumps are used in the BMS hp booster module. These pumps are centered within stainless - steel (duplex) sleeves. Inlet and outlet: 3" - type pipe joints.

    Horizontal multistage pump
    BMS 160 - 1A HP - C - C - P - A - A
    Number: 98494524

    Suitable for

    • Industrial water supply and transportation
    • Seawater desalination
    • Drinking water treatment

    The BMS booster module is suitable for industrial and water supply applications, with an inlet pressure of up to 80 bar. These booster modules are used to increase the system pressure


    Liquid


    • Liquid conveyed: Water
    • Liquid temperature range: 0 - 40 °C
    • Liquid temperature during operation: 20 °C
    • Density: 998.2 kg/m³


    Technology


    • Rated flow rate: 192 m³/h
    • Rated head: 20 meters
    • Rated flow rate (another value): 160 m³/h
    • Approvals: CE, TR
    • Curve tolerance: ISO9906:2012 3B


    Materials


    • Pump: Stainless steel (EN 1.4539, AISI 904L)
    • Impeller: Stainless steel (EN 1.4539, AISI 904L)
    • Motor: Aluminum
    • Sleeve: Super Duplex/Duplex steel (AISI 318 LN, EN 1.4462/1.4410)
    • Shaft seal: Silicon Carbide/Carbon


    Installation


    • Maximum ambient temperature: 40 °C
    • Minimum inlet pressure: 1 bar
    • Maximum permissible inlet pressure: 80 bar
    • Maximum permissible outlet pressure: 82.7 bar
    • Inlet and outlet: 6"/D168.3
    • Flange size for motor: FF 300


    Electrical data


    • Motor model: MGE
    • Frame size: 160MA
    • IE energy efficiency class: IE3
    • Rated power - P2: 15 kW
    • Power supply frequency: 50 Hz
    • Rated voltage: 3 x 380 - 480 V
    • Rated current: 26.7 - 22.0 A
    • Rated speed: 3540 revolutions per minute
    • Motor full - load efficiency: 91.9 %
    • Number of motor poles: 2
    • Enclosure rating (IEC 34 - 5): IP55


    Others


    • Minimum efficiency index, MEI ≥: 0.39
    • Net weight: 273 kg
    • Gross weight: 363 kg
    • Transport volume: 0.368 m³
