    Grundfos Ap50 Stainless Steel Submersible Pump Is Suitable for Pumping Surface Water and Groundwater

    UNILIFT AP50.50.11.A3.V
    Model of the submersible rainwater pump


    A vertical single-stage stainless steel submersible pump with a vertical outlet and an integrated submersible three-phase totally enclosed motor. The insulation class of the motor is F. The pump is also equipped with a suction filter.


    The pump is provided with a 10-meter power cable and a control box, which includes a motor starter and a motor protection device, as well as a 0.8-meter-long power cable. In addition, the pump is equipped with a level switch for automatic start and stop, with its own 10-meter-long cable.


    The impeller is a VORTEX impeller that allows a free passage of 50 millimeters. This makes it suitable for pumping surface water, groundwater and similar water.


    The pump has a double shaft seal and an intermediate oil reservoir pre-filled with non-toxic premium oil.


    The pump is equipped with a delivery pipe and a cooling jacket that continuously cools the motor through the conveyed liquid. Its ball bearings have deep grooves coated with grease, which gives it a long service life.


    Since the pump is equipped with a handle, it can be used at any time, and its power supply is completed through a 10-meter power cable. The power cable is of the socket type with a glass sealing compound inside the socket. The sealing compound can prevent moisture from entering the stator winding.


    Submersible sewage pump
    UNILIFT AP50.50.11.A3.V
    Number: 96010935

    Suitable for

    • Commercial sewage treatment
    • Domestic sewage treatment

    UNILIFT AP50 is a stainless - steel submersible pump used for pumping non - corrosive water and gray water with particles up to 50 mm in size. It can be used as a portable or fixed installation.



    Liquid:
    Liquid Temperature Range: 0 - 55 °C
    Liquid Temperature during Operation: 20 °C
    Density: 998.2 kg/m³

    Technology:
    Maximum flow: 8.89 liters per second
    Type of impeller: VORTEX
    Max. Particle: 50 millimeters
    Approvals: CE, RCM, LGABG, EAC, TUVRHWID, MORO, UKCA, CNROHSEXP, SEPRO

    Materials:
    Pump Casing: Stainless steel
    Pump housing: EN 1.4301
    Pump casing: AISI 304
    Impeller: Stainless steel
    EN 1.4301
    AISI 304
    Cable union: Brass
    CW602N
    C35330

    Installation:
    Ambient Temperature Range: 0 - 55 °C
    Interface Type: Rp
    Size of connection: 2 inch
    Maximum installation depth: 7 meters
    Place of installation: Indoor/outdoor

    Electrical Data:
    Power input P1: 1.9 kW
    Rated power - P2: 1.2 kW
    Power Supply Frequency: 50 Hz
    Rated voltage: 3 x 400 V
    Rated current: 3 A
    Cos phi - Power Factor: 0.88
    Rated driver speed: 2785 revolutions per minute
    Enclosure Rating (IEC 34-5): IP68
    Insulation class (IEC 85): F
    Length of power cable: 10 meters
    Cable Plug Type: NONE

    Others:
    Net Weight: 15.4 kg
    Gross weight: 18.5 kg
