Zoomlion Truck Crane 25 Tons Crane Truck ZTC250V4511, 5 sections of the longest 40-meter U-shaped main arm, the
maximum lifting torque of the basic arm is 960kN·m, the maximum
lifting torque of the full-extension arm is 598kN·m, and the
maximum lifting weight of the full-extension arm is 6t.
2, Sanqiao heavy-duty truck crane chassis platform, strong load
bearing, good passability, mobility, driving reliability. The
chassis meets the requirements of Class G vehicles without front
and rear guards.
3. Fully upgraded handling performance, rotary load sensitive
system, lifting adopts high-voltage automatic variable motor,
perfect balance of working speed, smoothness and micro-motion.
4, low operating costs, the use of gear pumps and variable motors,
operating fuel consumption reduced by more than 10%. The Weichai
WP7 engine and the Fast 8 gearbox are used to optimize the
powertrain matching and reduce fuel consumption by 10%.
5, green and environmentally-friendly brand new painting, new
two-room design, humanized detail design, with panoramic wide-body
control room, convenient and safe operation experience.
Performance ParametersItem | Value |
Working performance | Max. rated lifting capacity | kg | 25000 |
Max. load moment of basic boom | kN.m | 980 |
Max. load moment of main boom(fully extended) | kN.m | 573 |
Max. load moment of basic boom | m | 11.5 |
Max. lifting height of main boom | m | 33.8 |
Max. lifting height of jib | m | 41.6 |
Working speeds | Max. hoist rope speed(Main winch) | m/min | 120 |
Max. hoist rope speed(Auxiliary winch) | m/min | 100 |
Boom demrricking up time | s | 40 |
Boom demrricking up time | s | 66.5 |
Slewing speed | r/min | 0~2.2 |
Driving parameters | Maximum use altitude | m | 2000 |
Max. driving speed | km/h | 78 |
Max. gradeability | % | 37 |
Turning diameter | m | ≤22 |
Min. ground clearance | mm | 220 |
Oil consumption per hundred kilometers | L | 32 |
Dimensions | Overall dimensions(L×W×H) | mm | 12800×2500×3430 |
Outrigger spread(L) | m | 5.36 |
Outrigger spread(W) | m | Fully extended:6.1,Intermediately extended:4.2 |
Tail slewing radius | mm | 3385 |
Main boom length | m | 10.5~33.3 |
Boom angle | ° | -2~80 |
jib length | m | 8 |
Offset | ° | 0 , 30 |
Company Profile
FAQ
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete
line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction
machinery trading platform.we specialize in construction machinery
wholesale and concrete machinery re-manufacturing for more than 13
years.
3:What are the advantages of re-manufacturing machineries and what
quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We
set the highest maintenance and re-manufacturing standard
system,strictly inspect and repair according to the standard,Our
each re-manufacturing will go through 14 processes from admission
test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or
re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of
the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
