JLD-P02 Pcb Mainboard For Eletronic Scale Quad Core Development
Board ARM G52 2EE
Feature of JLD-P02 Mainboard For Eletronic Scale
- Stable System and Software Support: It supports the Android system, which has good stability and
compatibility and can run various self - service terminal
applications developed based on the Android system. At the same
time, it can be customized according to the needs of different
industries and users to meet special business needs and functional
requirements.
- Low - power Consumption Design: The RK3566 chip has been deeply optimized in terms of display
architecture, system task management, and hardware design to reduce
power consumption..This helps to save energy costs and extend the
service life of equipment, especially suitable for self - service
terminal equipment that needs to run for a long time.
Product interface photos of JLD-P02 Mainboard For Eletronic Scale
Hardware parameters of JLD-P02 Mainboard For Eletronic Scale
CPU | RK3566 Quad-core 64-bit Cortex-A55 processor, maximum frequency
1.8GHz |
| GPU | ARM G52 2EE support OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1 |
| NPU | 1TOPS |
Memory | 2G/4G/8G DDR4 optional |
EMMC | 16G-128G optional |
Display | Support LVDS,EDP,MIPI |
Audio Output | Stereo, support Dolby sound effect |
Audio port | 3.5mm headphone jack, 2P2.0 microphone interface, 4P2.0 speaker
interface |
Ethernet | 10/100M |
Wi-Fi | 2.4G/5G WiFi BT |
OS | Android 11/ Ubuntu 20.04/Debian 10 |
| TP | I2C /USB interface TP |
Memory card type | TF-CARD |
USB Interface | Built-in USB 2.0 sockets (4 pcs), external USB 2.0 (2 pcs) 3.0 (1
pce) OTG (1 pce) |
Serial port | 5 in total, optional types, TTL (1-5 pcs), RS232 (0-4 pcs) |
RTC | Support power-off clock memory, automatic power on and off |
Camera | USB camera |
PCB Size | 125mm*90mm*1.6mm |
Power supply | DC12V-24V input |
| Temperature | -20°- 80℃ |
Applications
POS machine, electronic scale, self-service terminal
Packing
1. At Buyer's Request;
2. Inner, vacuum package;
3.Outer, standard export carton;
FAQ
Q1. Can I have a sample order for PCBA motherboard?
A: Yes, we welcome sample order to test and check quality with your
equipment. Customized development PCBA are available well.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for
order quantity more than
Q3. Do you have any MOQ limit for trial order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5
days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for PCBA motherboard?
A: Firstly let us know your requirements or application.Secondly We
quote according to your requirements or our suggestions.Thirdly
customer confirms the samples and places deposit for formal
order.Fourthly We arrange the production.
Q6. Is it OK to print my logo on PCBA motherboard product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-3 years warranty to our products.
Any inquiry, please leave message to us!
