HPP High Pressure Processing Machine For Sterilizing

    Buy cheap HPP High Pressure Processing Machine For Sterilizing from wholesalers

    Buy cheap HPP High Pressure Processing Machine For Sterilizing from wholesalers
    • Buy cheap HPP High Pressure Processing Machine For Sterilizing from wholesalers

    HPP High Pressure Processing Machine For Sterilizing

    Ask Lasest Price
    Brand Name : sss
    Model Number : customized
    Price : 485294
    Payment Terms : L/C, T/T
    Supply Ability : 10set/y
    Delivery Time : 80-120days
    • Product Details
    • Company Profile

    HPP High Pressure Processing Machine For Sterilizing

    HPP High Pressure Processing Machine For Sterilizing


    Equipment specification



    item

    specification
    materialSpecial alloy stainless steel, compliant with ASME U3 material requirements in the United States

    Ergonomic approach


    Horizontal design, in line with ergonomics, makes loading and feeding more convenient;

    Horizontal design helps with any food line connection, convenient and hygienic

    Feeding/UnloadingAutomatic loading and unloading system enables HPP equipment to be automated

    Safety indicators


    The equipment adopts prestressed steel strip winding technology to ensure safe operation under ultra-high pressure conditions of 600MPa fully stable.

    The prestressed steel strip winding structure technology is the most advanced technology for manufacturing ultra-high pressure vessels and large-scale pressure equipment


    Applying prestress to containers and load-bearing frames that bear huge loads through steel strip winding,significantly reducing stress and increasing fatigue strength in the synthesized state, completely eliminating stress concentration

    Electricity usage


    Adopting the latest generation of variable frequency control system, significantly reducing electricity consumption and lower energy consumption

    Technical parameter

    itemspecification
    Max working pressure:600mpa
    Effective volume of working chamber57L
    Capacity:200-300l/h(based on packing)
    Working fluid mediumpure water
    Increasing pressure timeabout 240s
    Pressure holding time0-3000s
    Pressure decrease after 5min≤5%(can set automatic pressure replenishment when the pressure drops)
    Increase pressure methodReciprocating continuous pressurization
    Pressure relief methodInstantaneous automatic pressure relief
    dimensionAbout 8700*4500*3000mm
    weightAbout 18t

    Quality HPP High Pressure Processing Machine For Sterilizing for sale
