CA40MM 1-1/2'' Embedded Dust Collector Pulse Valve 12V 24V 110V
220V
When the pulse electromagnetic pulse valve is not energized, the
gas enters the decompression chamber through the constant pressure
pipes of the upper and lower shells and the throttle holes in them.
Because the valve core blocks the pressure relief holes under the
action of the spring, the gas will not be discharged. Make the
pressure of the decompression chamber and the air bag the same, and
under the action of the spring, the diaphragm will block the
blowing port, and the gas will not rush out. 2. When the pulse
valve is energized, the valve core is lifted up under the action of
electromagnetic force, the pressure relief hole is opened, and the
gas is ejected. Due to the effect of the constant pressure pipe
orifice, the outflow speed of the pressure relief hole is greater
than that of the pressure relief chamber. The inflow speed of the
pressure pipe gas makes the pressure of the air bag lower than the
pressure of the lower air chamber, and the gas in the air bag
pushes up the diaphragm, opens the blowing port, and performs gas
blowing.
Technical Data of CA40MM Electromagentic Valve:
| Model No. | CA40MM |
| Port Size | G1-1/2'' |
| Diameter (mm) | 40 |
| Number of Diaphragm | 2 |
| Valve Type | Full Immersion Manifold Flat Mount Valve |
| Working Medium | Air |
| Pressure Range | 0.3~0.8Mpa |
| Working Temperature | -5~+55℃ |
| Seal Material | NBR(common, all avaliable) |
| Body Material | Aluminum Alloy |
Construction of MM series pulse valve:
Body and Dresser Nuts: Aluminium (diecast)
Ferrule: 305 SS
Armature: 430FR SS
Diaphragm and seals: Nitrile or Viton
Spring: 304 SS
Screws: 302 or 304 SS
Outlet pipe: Schedule 40 wrought steel zinc
passivatedDiaphragm Seat: PA-66 (25 & 40MM standard),
Nitrile-coated mild steel (76MM standard), Acetal (102MM standard)
or Vitoncoated mild steel
Features and benefits of CA40MM:
1. Installation easily, MM valves are installed through the tank.
2. Sensitive and reliable signal; Stable working
3. Low internal-resistance;Long operating-life
4. Most powerful air pulse due to full immersion design ; Large
gas-displacement;High airflow impact-force
5. Ready for use in any dust collector design
6. Cost savings; urable materials and wide temperature range
enhance lifespan ;Longer filter life, lower dust collector OPEX
7. With environmental and health & safety regulations
