Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

    Buy cheap Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K from wholesalers

    Buy cheap Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K from wholesalers
    • Buy cheap Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K from wholesalers

    Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

    Ask Lasest Price
    Brand Name : Zhongdong
    Model Number : H1Z2Z2-K
    Certification : CCC,IEC,VDE,TUV,ISO
    Price : Negotiable
    Payment Terms : L/C,T/T
    Supply Ability : 500KM/Week
    Delivery Time : 10work days
    • Product Details
    • Company Profile

    Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

    Copper Core Control Cable PVC Insulated PVC Sheathed Control Cable H1Z2Z2-K

    Application


    DC Solar Cables

    The interconnection between photovoltaic modules

    Parallel connection between series and between modules and DC distribution boxes (combiner boxes)

    Connection between DC distribution boxes and inverters.

    AC Solar Cables

    Connecting inverters to step-up transformers

    The connection between the step-up transformer and the distribution equipment

    The connection between power distribution equipment and the power grid or user


    Description

    1. Fire Resistance
    2. Low Smoke and Toxicity‌:
    3. Insulation Materials‌:
    4. Durability‌:
    5. Compliance‌:

    Structure

    Conductor: Tinned copper, offering excellent conductivity and corrosion resistance.

    Insulation: Cross-linked polyethylene (XLPO) or similar material, providing high thermal and mechanical resistance.

    Sheath: Halogen-free, flame-retardant material, ensuring safety and environmental compliance.

    Electrical Characteristics

    Cross section(mm²)

    Conductor Construction(no/mm)

    Conductor Stranded OD.max(mm)

    Cable OD.(mm)

    Approximate weight of cable
    kg/km

    Max Conductor Resistance(Ω/km,20°C)

    1×1.5

    48/0.20

    1.58

    4.8

    35

    13.7

    1×2.5

    77/0.20

    2.02

    5.2

    47

    8.21

    1×4

    56/0.285

    2.46

    5.7

    64

    5.09

    1×6

    84/0.285

    3.01

    6.3

    86

    3.39

    1×10

    77/0.40

    4.1

    7.2

    128

    1.95

    1×16

    7×17/0.40

    5.5

    8.9

    196

    1.24

    1×25

    7×27/0.40

    6.7

    10.7

    299

    0.795

    1×35

    7×38/0.40

    8.2

    12.4

    407

    0.565

    1×50

    19×20/0.40

    10.0

    14.6

    571

    0.393

    1×70

    19×28/0.40

    11.6

    16.4

    773

    0.277

    1×95

    19×38/0.40

    13.5

    18.5

    1024

    0.210

    1×120

    24×38/0.40

    14.4

    19.8

    1266

    0.164

    1×150

    30×38/0.40

    16.2

    22.2

    1584

    0.132

    1×185

    37×38/0.40

    18.2

    25.0

    1967

    0.108

    1×240

    48×38/0.40

    20.6

    27.8

    2518

    0.0817


    Quality Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K for sale
