    Portable Particle Counter KGD - OPC - 202


    Product Introduction


    The portable particle counter KGD - OPC - 202 adopts the principle of optical scattering. It can accurately detect and calculate the number of suspended particulate matters with different particle sizes in the air per unit volume. It is equipped with a built-in dust source intelligent recognition module unique to Sifang Optoelectronic, and has a high gas sampling rate of 28.3L/min. It can simultaneously output the particle numbers of five channels: 0.3μm, 0.5μm, 1.0μm, 5.0μm, and 10μm (the default unit is pcs/28.3L, and it can be switched to pcs/m³). The indication error meets the JJF - 1190 standard.

    Technical Parameters


    Number of ChannelsMulti-channel (0.3μm, 0.5μm, 1.0μm, 5.0μm, 10μm)
    Counting Efficiency50%@0.3μm 100%@≥0.5μm (Under the environmental conditions of 25±2℃, 50±10%RH)
    Detection Range0 - 1,000,000 pcs/28.3L
    Power-on Stabilization Time≤8s
    Data Refresh Frequency1s
    Operating Conditions0℃ to 45℃; 0 - 95%RH (non-condensing)
    Storage Conditions-20℃ to 60℃, 0 - 95%RH (non-condensing)
    Operating VoltageDC 24.0V±15%
    Battery Standby Time>5h (Working for 2 minutes and sleeping for 28 minutes)
    Average Operating Current≤3A
    Communication InterfaceRS485 interface (Standard configuration) RJ45 (Standard configuration)
    Product Lifespan≥3 years
    Sampling Flow28.3L/min
    Sampling HeadIsokinetic sampling probe
    External Sampling TubeInner diameter: ф10mm Length: ≤3m
    Operating ModeAdjustable (Default: Working for 2 minutes and sleeping for 28 minutes)
    Display7-inch color screen
    CalibrationJJF 1190-2008
