Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine

    Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers

    Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers
    • Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers
    • Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers
    • Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers
    • Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers
    • Buy cheap Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine from wholesalers

    Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine

    Ask Lasest Price
    Certification : CE ISO TUV
    Brand Name : Xrido
    Model Number : Customizable
    Delivery Time : 2-30 Working Days
    Payment Terms : Negotiable
    • Product Details
    • Company Profile

    Waste Aluminum Shredder Steel Scrap Car Shell Shredder Machine

    Products Description:
    Aluminum scrap shredder is a professional heavy-duty mechanical equipment, mainly used to break large-sized aluminum scrap materials (such as aluminum alloy wheels, aluminum profiles, aluminum doors and windows, etc.) into small particles through mechanical forces such as shearing and extrusion, which is convenient for subsequent sorting and recycling. Its core components include double-axis knife rollers, alloy knives and automatic iron removal systems. The motor drives the knife shafts to rotate in opposite directions to shred the materials, and at the same time, it can separate iron impurities to improve the purity of aluminum materials. This equipment plays an important role in resource recycling and environmental protection, and can significantly reduce the transportation cost of aluminum scrap and improve smelting efficiency.



    model
    size(mm)
    Shredder room(mm)
    Blads(mm)
    motor(k)
    weight(kg)
    XD-600
    2800×1300×1850
    600×480
    200
    11×2
    2200
    XD-800
    3000×1300×1850
    800×480
    200
    15×2
    2500
    XD-1000
    3300×1900×2200
    1000×690
    300
    22×2
    5200
    XD-1200
    3600×2000×2200
    1200×690
    300
    30×2
    6400
    XD-1500
    4180×2100×2400
    1500×850
    550
    55×2
    9000
    XD-1800
    5800×2400×3300
    1800×1206
    550
    75×2
    13600
    XD-2000
    6400×2700×3500
    2000×1490
    600
    90×2
    20100
    XD-2500
    7500×3200×3800
    2500×1800
    600
    110×2
    25000
    Notes:
    1. The number of blade claws, diameter, and thickness can be customized according to the type of material and the size of the discharge.
    2. The output of the equipment will be different depending on the type of material and the size of the discharge.
    3. More information please contact us, we can custom the product on your request.

    Process flow of car shell shredder:

    Feeding stage: The waste car shell is fed into the shredder feed port through a conveyor belt, hopper or loader. The feed port is usually designed to be larger to accommodate large volumes of materials

    Primary crushing: After the material enters the crushing chamber, it is sheared and torn by the rotating knife and extrusion, and are broken down into larger fragments
    Secondary crushing: The fragments continue to be hit and torn multiple times in the crushing chamber, and the size is further reduced
    Screening and separation: The crushed materials are screened through the screen to achieve the initial separation of metal materials and plastic parts
    Discharging stage: The materials that meet the size requirements are discharged from the discharge port and enter the subsequent processing link
    Technical advantages:
    High-efficiency processing capacity of the car shell shredder:
    The high-strength tool design of the car shell shredder can achieve fast and efficient crushing, and process a large amount of materials in a short time. The car shell shredder can process several tons of waste car shells per hour, greatly improving the recycling efficiency.

    Case:


    Large car shell shredder is an industrial crushing equipment specially used for processing waste car shells, and is a type of solid waste treatment machinery. It uses mechanical force to tear, crush and decompose waste car shells (including steel, aluminum alloy and other materials) into small pieces that are easy to process and recycle.
