Model Number : | XZH PCB |
Brand Name : | XZH PCBA |
Supply Ability : | 300000 Piece/Pieces per Week |
Price : | CN¥7.21/pieces >=1 pieces |
SMT | Position accuracy:20 um |
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP | |
Max. component height::25mm | |
Max. component height::25mm | |
Max. PCB size:680×500mm | |
Min. PCB size: no limited | |
PCB thickness:0.3 to 6mm | |
Wave-Solder | Max. PCB width:450mm |
Min. PCB width: no limited | |
Component height:Top 120mm/Bot 15mm | |
Sweat-Solder | Metal type :part, whole, inlay, sidestep |
Metal material:Copper , Aluminum | |
Surface Finish:plating Au, plating sliver , plating Sn | |
Air bladder rate:less than20% | |
Testing | ICT,Probe flying,burn-in,function test,temperature cycling,AXI – 2D
and 3D automated X-ray inspection, AOI – automated optical
inspection |
Base material | FR4,High-TG FR4,CEM3,aluminum, High Frequencey
frequency(Rogers,Taconic,Aron,PTFE,F4B) |
Layers | 1-4 Layers(Alunimum), 1-32 layers(FR4) |
Aluminum Machining | Drilling, Tapping, Milling, Routing, Die-Punching, Break-off tab available |
Min SMD Pad Pitch | 0.2mm (8mil) |
Surface Finishing | HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP |
Solder Mask Color | Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black,
Matt Blue |
Legend Color | Black, White etc |
Assembly Types | Surface mount Thro-hole Mixed technology (SMT & Thru-hole) Single or double sided placement Conformal coating Shield cover assembly for EMI emission control |
Component types | SMT 01005 or larger BGA 0.4mm pitch, POP (Package on Package) WLCSP 0.35mm pitch Hard metric connectors Cable & wire |
Stencils | Laser-cut stainless steel |
Sample Lead time | Mass production lead time | |||
Single sided PCB | 1~3 days | 4~7 days | ||
Double sided PCB | 2~5 days | 7~10 days | ||
Multilayer PCB | 7~8 days | 10~15 days | ||
PCB Assembly | 8~15 days | 2~4 weeks | ||
Delivery time | 3-7 days | 3-7 days | ||
Package: Anti-static Package with carton |
![]() |
