    3DT350-B Three Axis Simulation Inertial Test Electric Turntable

    3DT350-B Three-axis Simulation Inertial Test Electric Turntable


    Product Description


    The three-axis electric turntable integrates the three axis of azimuth, pitch and roll, and can simulate the full attitude motion of aircraft, satellites and other equipment. It is widely used in the calibration and verification of inertial measurement units (IMU) and integrated navigation systems. The open software interface supports customized motion trajectory programming, coupled with real-time data monitoring functions, provides efficient and reliable solutions for device performance testing in complex environments, and assists the development and optimization of high-precision equipment.


    Product Parameters


    Specification

    1

    Load Weight

    15Kg

    2

    Maximum size of test piece

    255mm×255mm×150mm

    3

    Rotary Accuracy Of Three-Axis

    ±5″

    4

    Perpendicularity Of Three-Axis

    ±6

    5

    Intersection Of Three-Axis

    Ф0.5mm diameter ball

    6

    Positioning Error Of Angular Position

    ±8

    7

    Positioning Repeatability Of Angular Position

    ±8

    8

    Rate Range

    inner frame:0.01°/s~200°/s

    middle frame:0.01°/s~100°/s

    outer frame:0.01°/s~100°/s

    9

    Rate Accuracy

    ω≤1°/s , 2×10-3 (1° average)

    1°/s≤ω<10°/s , 2×10-4 (10° average)

    ω≥10°/s , 2×10-5 (360° average)

    10

    Maximum Angular Acceleration

    inner frame:≥100°/s²

    middle frame:≥100°/s²

    outer frame:≥50°/s²

    11

    User Slip Ring

    Customizable

    12

    Table body dimensions

    654mm×654mm×600mm
