5.0 Inch 800x480dots IPS LCD IC ILI5960 ILI6122 TFT LCD Display
Capacitive Touch Screen
Product Description
800*480dots IPS TFT LCD Display 5.0 Inch Capacitive Touch Screen
Sunlight Readable Ips Tft Lcd Display 800*480 5.0 Inch Capacitive
Touch Screen
Description of tft touch display
The T050BWV40I1K004-CT is a high-quality, 5” TFT LCD display module
manufactured by Chenghao Lcd, a company located in Shenzhen, China.
The module incorporates IPS technology and features a 800x480
resolution, providing high-quality and sharp images. It is a
versatile display module that can be widely used in various devices
that require color views such as smart coffee machines.
Quick details of custom lcd module
Module Name: High Brightness Screen
Module No.:T050BWV40I1K004-CT
LCD Type: 5” TFT, IPS
Viewing Direction: 80/80/80/80 (All viewing angles)
Active Area: 108(W)×64.8(H)mm
Resolution: 800 x 480dots
Module Size: 120.7(W)×75.8(H)×4.35(T) mm
FPC Pin Number: 40 pins
Backlight Color: White
Backlight: 18 White LEDs in serial
Luminance: 600 cd/m2 High Brightness(optional)
Display Type: IPS/Transmissive / Normally Black
Operating Temperature: -20 ~ +70 ℃ (wide temperature)
Storage Temperature: -30 ~ +80 ℃
Life Time: 20,000 hours
Input/Output Terminals
Advantages of ips lcd screen
High-quality display module with a high brightness of 600 cd/m2 for
easy viewing in any lighting condition.
Wide viewing angle to provide a clear view from almost any angle.
Versatile product that can be used in various devices such as smart
coffee machines.
The module is designed with a wide temperature range (-20 ~ +70 ℃)
to operate in different environments.
The product comes with RoHS, CE, and FCC certificates, ensuring
that it meets strict quality standards.
The manufacturer offers one-stop liquid crystal display solutions,
which is useful for customers who need customization services.
FAQ
Q: What is the maximum luminance of the T050BWV40I1K004-CT?
A: The maximum luminance of the product is 600 cd/m2.
Q: What is the backlight color of the T050BWV40I1K004-CT?
A: The backlight color of the product is white.
Q: What temperature range can the T050BWV40I1K004-CToperate in?
A: The product can operate in a wide temperature range of -20 ~ +70
℃.
Q: Does the T050BWV40I1K004-CT come with any certificates?
A: Yes, the product has RoHS, CE, and FCC certificates.
Q: What is the warranty period for the T050BWV40I1K004-CT?
A: The product has a one-year warranty period.
Q: What is the MOQ for the T050BWV40I1K004-CT?
A: The MOQ for the product is 1 piece.
Q: What is the delivery period for the T050BWV40I1K004-CT?
A: The delivery period for the product is 7-15 working days.
Q: How do I pay for my order?
A: Payment for orders can be made via T/T.
