3104 Alloy 1.2mm Thickness Polyester Paint Aluminium Roofing Coil
For Construction Material
We offers pre-painted aluminum coil and sheet in the most popular
colors in the market.
The 3xxx series aluminum substrate provides an excellent surface for paint, has
good cold workability,
is weldable, and has very good corrosion resistance ability.
we export it with 2 kinds forms
coil and sheet , our equipment can produce 1800mm width at most for the coil.
Mirror Finish Surface
Our company's pre-painted aluminum coils are available in a widely
variety of colors, finishes
and patterns. They are light weight, easy to install, and have excellent formability,
making them
ideal for various applications including building roofing, indoor ceiling, shutter and more.
Stand Colors
We can customize the color as your sample, the following colors are just examples.
Pattern Surface, wood as example
these advantages below
♦ Coated aluminium coil can form alumina film with the atmosphere to prevent the further corroded.
♦ Aluminum material is 100% recyclable and keeps its original
characteristics during the recycling process.
♦ Painted aluminium material provide superior UV resistance
Basic Parameters
| Thickness Range | 0.20 - 5mm |
| Width Range | Max. 1800mm |
| Alloy | 1060, 3003, 3004,3105 |
| Paint System | PE, SMP, PVDF |
| Color Options | Ral color or as the sample |
| Temper | H22, H24, H26 |
| Trade Terms | FOB,CIF,CFR,EXW |
Widely Applications
| Thickness | Typical Usage |
| 0.5-1.0mm | indoor decoration, home appliance panel |
| 1.0-1.5mm | building roofing, railway transportation, indoor and outdoor wall |
| 1.5-3.0mm | high-rise curtain wall, industrial equipment, durable structure |
| 3.0-6.0mm | heavy-duty curtain wall, vessel, aerospace, special industry |
It is widely used in aluminum plastic panel (ACP), grille, ceiling,
roofing, shutter, curtain wall and electronic products.
Painted aluminum sheet could be used for 28 years with its stable
performance, anti-corrosion and light weight.
Packages and Loading
Standard export packages: 3 layers. Inside is craft paper, Middle is water proof plastic film, outside is hard
paper sheet to be covered by steel strips with lock.
To prevent the rolling, tipping and sliding of the Painted
Aluminium coils in the container three more common phenomena,
The reinforcement materials used are mainly wood strips, wood
plugs, wire ropes and auxiliary equipments.
