GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free

    Buy cheap GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free from wholesalers

    Buy cheap GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free from wholesalers
    • Buy cheap GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free from wholesalers

    GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free

    Ask Lasest Price
    Brand Name : Radici
    Model Number : PA66 GT3300HSL BK20
    Certification : MSDS
    Price : USD3.2-4KG
    Payment Terms : T/T
    Supply Ability : 500TONS
    Delivery Time : 5-14days
    • Product Details
    • Company Profile

    GT3300HSL BK20 Pa66 Material Injection Grade Pa66 25gf Halogen Free


    Products Description




    Radigi PA66 GT3300HSL BK20 Glass Fiber Reinforced 25% Injection Grade Halogen-Free Flame Retardant V0 High Strength Household Appliances


    Multi-purpose high performance: PA66 GT3300HSL BK20 is a multi-purpose high performance polyamide with high mechanical strength and stiffness, good electrical insulation properties, excellent heat resistance, chemical resistance and wear resistance.
    Machinability: The material has good color stability, universal easy injection molding, making the processing more convenient.
    Wide range of applications: PA66 GT3300HSL BK20 is suitable for automotive parts, connectors, electronic parts, mechanical configuration, building materials and other fields

    product feature

    PA66
    GT3300HSL BK20
    Product information
    Other CertificatesMSDS
    Part Marking Code>PA66-I-GF33<
    ColorBK
    Material ShapePellets
    ProcessInjection molding
    Material AttributeImpact modified 33%Glass Fiber Reinforced Injection grade Heat stabilized grade
    Features·High impact ·High stiffness
    Automotive Specifications·FORD WSS-M4D703-B1
    AdditivesHeat Stabilizer Impact modifier
    Certificate
    Physical propertyStandardValueUnit
    DensityISO 11831.34g/cm³
    Shrinkage FlowISO 2940.50~0.70%
    Shrinkage xFlowISO 2940.30~0.50%
    Water Absorption 23℃ Saturation 2.00mmISO 621.1%
    Water
    Absorption 23℃ 50RH Equilibrium 2.00mm
    ISO 621.7%
    Mechanical behaviorStandardValueUnit
    Tensile ModulusISO 5271450000psi
    Tensile Strength BreakISO 52724700psi
    Elongation BreakISO 5274.0%
    Flexural Strength 2.0mm/minISO 17836300psi
    Flexural Modulus 2.0mm/minISO 1781150000psi
    Izod Notch Impact 23℃ISO 1809.5ft · Ib/in²
    Charpy Notch ImpactISO 1797.1ft · Ib/in²
    Charpy Notch ImpactISO 17910ft.Ib/in²
    ThermalStandardValueUnit
    HDT Unannealed 0.45MPaISO 75491F
    HDT Unannealed 1.8MPaISO 75477F
    Melting Temperature 10℃/minISO 11357504F
    Injection moldingValueUnit
    Dry Temperature176F
    Dry Time2.0~4.0hr
    Water Content Control≤0.15%
    Melt Temperature536~572F
    Mould Temperature176~212F
    Injection SpeedModerate-Fast
    Dew Point-4.0F

    Application



    Optical lighting


    It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

    Electronic appliances

    It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

    Mechanical equipment

    It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields


    Physical Property Parameter​


    Company Profile:


    Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

    The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.
    Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.
    We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.
    our Product Range Includes Engineering Materials And General Mater

    Warehouse:


    FAQ
    How about our package?
    1.All the packing can be customized.
    2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.
    3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to
    handle the dosage.
    What are our business principles?
    1.For the trial order, 1tons will be acceptable.
    2.We will do our best for the customer as long as you choosing us.
    3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.
    What are the advantages of our shipping and delivery?
    1.We make sure all the products will be inspected strictly before loading.
    2.We will make the shipment within 7 days after confirm the payment.
    3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

    ApplicationElectronics electrical appliances mobile phones cars
    GradeInjection Grade,Extrusion Grade
    OEM/ODMAccepted
