    XP4025-BK1023 ASA PC Material Weather Resistant Energy Alloy Plastic

    Ask Lasest Price
    Brand Name : American basic innovation
    Model Number : ASA/PC XP4025-BK1023
    Certification : MSDS
    Price : USD2.5-3KG
    Payment Terms : T/T
    Supply Ability : 500T
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    XP4025-BK1023 ASA PC Material Weather Resistant Energy Alloy Plastic

    Products Description



    ASA/PC American basic innovation XP4025-BK1023 weather resistant energy alloy plastic

    ASA/PC American basic innovation XP4025-BK1023 weather resistant energy alloy plastic

    product feature

    SABIC Innovative Plastics GELOY XP4025 ASA+PC(Asia Pacific)
    Polycarbonate/ASA Alloy,Unreinforced
    SABIC Innovative Plastics(GE Plastics)

    product description
    ASA+PC blend.Weatherable,injection grade.Available in a wide range of colors and is recommended for unpainted exterior applications.
    Physical propertyRated value(metric)Rated value(English)Test method
    Proportion


    Water absorption
    1.14 g/cc1.14 g/ccASTM D792
    0.24%0.24%
    @Time 86400 sec@Time 24.0 hourASTM D570
    Linear molding shrinkage,0.0050-0.0070 cm/cm0.0050-0.0070 in/in
    Flow@Thickness 3.20 mm@Thickness 0.126 inSABIC Method
    Linear molding shrinkage,0.0050-0.0070 cm/cm0.0050-0.0070 in/in

    transverse

    Melt flow rate
    @
    @Thickness 3.20 mm@Thickness 0.126 inSABIC Method
    18 g/10 min18 g/10 min
    Load 5.00 kg,Temperature 260℃@Load 11.0 Ib,Temperature 500FASTM D1238
    Mechanical behaviorRated value(metric)Rated value (English)Test method
    Rockwell hardness(R class)114114ASTM D785
    Tensile strength(yield)59.0 MPa8560 psiType I,50 mm/min;ASTM D638
    Elongation(break)25%25%Type I,50 mm/min;ASTM D638
    bending strength88.0 MPa12800 psi1.3 mm/min,50 mm span;ASTM
    flexural modulus2.58 GPa374 ksi1.3 mm/min,50 mm span;ASTM
    Impact strength of hanging beam

    gap
    1.70J/cm3.18 ft-lb/inASTM D256
    0.640 J/cm1.20 ft-Ib/in
    @Temperature -30.0℃@Temperature -22.0°FASTM D256

    Dart Drop,Total Energy
    33.0J24.3 ft-Ib
    @Temperature -30.0℃@Temperature -22.0FASTM D3763
    37.0J27.3 ft-Ib
    @Temperature 23.0℃@Temperature 73.4°FASTM D3763
    Hot propertyRated value(metric)Rated value (English)Test method
    Linear thermal expansion72.0μm/m-℃40.0 μin/in-F
    coefficient-flow@Temperature -20.0-150℃@Temperature -4.00-302FASTME831
    Linear thermal expansion coeffi-72.0 μm/m-℃40.0 μin/in-F
    cient,lateral flow@Temperature -20.0-150℃@Temperature -4.00-302FASTM E831
    Thermal conductivity0.250 W/m-K1.74 BTU-in/hr-ft²-FASTM C177
    Thermal deformation temperature102℃216F
    under load(0.46 MPa)@Thickness 3.20 mm@Thickness 0.126 inunannealed;ASTM D648
    Thermal deformation temperature90.0℃194F
    under load (1.8 MPa)@Thickness 6.40 mm@Thickness 0.252 inunannealed;ASTM D648
    UL RTI50.0℃122FUL 746B
    UL RTI Mechanical shock50.0℃122FUL 746B
    UL RTI,no mechanical impact50.0℃122FUL 746B
    Flammability(UL94)HB

    @Thickness 1.47 mm
    HB

    @Thickness 0.0579 in
    UL94
    Optical performanceRated value(metric)Rated value (English)Test method
    glossiness90%90%untextured,60 degrees;ASTM D5

    Application


    Optical lighting


    It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

    Electronic appliances

    It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

    Mechanical equipment

    It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields


    Physical Property Parameter​


    Company Profile:


    Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

    The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.
    Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.
    We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.
    our Product Range Includes Engineering Materials And General Mater

    Warehouse:


    FAQ
    How about our package?
    1.All the packing can be customized.
    2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.
    3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to
    handle the dosage.
    What are our business principles?
    1.For the trial order, 1tons will be acceptable.
    2.We will do our best for the customer as long as you choosing us.
    3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.
    What are the advantages of our shipping and delivery?
    1.We make sure all the products will be inspected strictly before loading.
    2.We will make the shipment within 7 days after confirm the payment.
    3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

    ApplicationElectronics electrical appliances mobile phones cars
    GradeInjection Grade,Extrusion Grade
    OEM/ODMAccepted
