    420SE0 Polybutylene Terephthalate Resin Injection Molding GF30 Heat Resistance

    Ask Lasest Price
    Brand Name : Saber Foundation
    Model Number : PBT 420SE0
    Certification : MSDS
    Price : USD3-3.8KG
    Payment Terms : T/T
    Supply Ability : 500TONS
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    420SE0 Polybutylene Terephthalate Resin Injection Molding GF30 Heat Resistance


    Products Description



    Saber Foundation PBT 420SE0 resin Injection molding GF30 Flame retardant V0 Heat resistance high rigidity high strength


    The PBT 420SE0 has a wide range of applications due to its good performance
    Electronic and electrical fields: can be used for cutting machine, food mixer motor stator and commutator, electric fan, connector, spool, switch and other products. These products usually require materials with good electrical, mechanical and flame retardant properties, and the PBT 420SE0 meets these requirements.
    Automotive field: Due to its good mechanical properties, heat resistance and dimensional stability, it can also be applied to automotive parts, such as car bumpers, carburetors, spark plugs, oil supply system parts, igniters and so on

    product feature

    PBT
    420SEO
    Product information
    Other CertificatesMSDS
    Part Marking Code>PBT-GF30-FR(17)<
    Pellets
    Material Shape
    ProcessInjection molding
    FRV-2 V-05VA
    Material Attribute30%Glass Fiber Reinforced Halogen Injection grade
    specification·UL-746C F2 ·RoHS ·UL
    Features
    Application·Bobbins·Connector ·Switches·Commutators·Industrial
    Halogen Flame Retardant Agent
    coolingfan·Industrial electric
    Additives
    UL File NO.E121562
    CertificateUMSDS
    Physical propertyStandardValueUnit
    DensityASTM D7921.63g/cm³
    DensityISO 11831.63g/cm³
    Shrinkage FlowINTERNAL METHOD0.1~0.5%
    Shrinkage Flow 3.2mmINTERNAL METHOD0.5~0.7%
    Shrinkage xFlowINTERNAL METHOD0.4~0.8%
    Shrinkage xFlow 3.2mmINTERNAL METHOD0.5~1%
    Water Absorption 23℃ SaturationISO 620.09%
    Water Absorption 23℃50RHISO 620.07%
    Melt Index 250℃5kgASTM D123842g/10min
    Melt Index 250℃ 5kgISO 113329cm³/10min
    Specific VolumeASTM D7920.61cm³/g
    Outdoor SuitabilityUL 746Cf2
    HardnessStandardValueUnit
    Rockwell Hardness R(Scale)ASTM D785119
    Rockwell Hardness R(Scale)ISO 2039119
    Ball Indentation Hardness H358/30ISO 2039118MPa
    Mechanical behaviorStandardValueUnit
    Tensile Modulus 5mm/minASTM D63812000MPa
    Tensile Modulus 1.0mm/minISO 52710000MPa
    Tensile Strength Yield 5mm/min Type IASTM D638120MPa
    Tensile Strength Break 5mm/min Type IASTM D638120MPa
    Tensile Strength Yield 5mm/minISO 527120MPa
    Tensile Strength Break 5mm/minISO 527120MPa
    Elongation Yield 5mm/min Type IASTM D6382%
    Elongation Break 5mm/min Type IASTM D6382%
    Elongation Yield 5mm/minISO 5271.9%
    Elongation Break 5mm/minISO 5271.9%
    Flexural Strength Break 1.3mm/minASTM D790186MPa
    Flexural StrengthISO 178180MPa
    Flexural Modulus 1.3mm/minASTM D7909800MPa
    Flexural Modulus 2.0mm/minISO 1789500MPa
    Izod Notch Impact 23℃ASTM D25660J/m
    Izod Notch Impact -30℃ASTM D25657J/m
    Izod Notch Impact 23℃4.0mm Type AISO 1807kJ/m²
    Izod Notch Impact -30℃4.0mm Type AISO 1806kJ/m²
    Izod Un-notch Impact 23℃ASTM D4812620J/m
    Izod Un-notch Impact 23℃4.0mmISO 18045kJ/m²
    Izod Un-notch Impact -30℃4.0mmISO 18045kJ/m²


    Optical lighting


    It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

    Electronic appliances

    It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

    Mechanical equipment

    It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields


    Physical Property Parameter​


    Company Profile:


    Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

    The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.
    Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.
    We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.
    our Product Range Includes Engineering Materials And General Mater

    Warehouse:


    FAQ
    How about our package?
    1.All the packing can be customized.
    2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.
    3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to
    handle the dosage.
    What are our business principles?
    1.For the trial order, 1tons will be acceptable.
    2.We will do our best for the customer as long as you choosing us.
    3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.
    What are the advantages of our shipping and delivery?
    1.We make sure all the products will be inspected strictly before loading.
    2.We will make the shipment within 7 days after confirm the payment.
    3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

    ApplicationElectronics electrical appliances mobile phones cars
    GradeInjection Grade,Extrusion Grade
    OEM/ODMAccepted

    Quality 420SE0 Polybutylene Terephthalate Resin Injection Molding GF30 Heat Resistance for sale
