Premium Acoustic Partition Walls
Our acoustic partition walls, also known as sliding folding
partitions or room dividers, are renowned worldwide for their
top-tier quality, versatile design, acoustic efficiency, and
enduring durability. Manufactured in China, these partitions
feature a sturdy aluminum frame and come in various sizes,
performance levels, and decorative finishes.
Versatile and Durable Design
We excel in producing and exporting banquet hall acoustic partition
walls to a diverse range of international markets. Available in
three different wall thicknesses, our partitions offer impressive
durability and can accommodate taller structures. Choose from a
broad selection of acoustic and decorative surface options tailored
to your specific needs.
Outstanding Acoustic Performance
Designed to minimize sound transmission and absorption, our
partitions significantly reduce acoustic reflections and improve
soundproofing. They are ideal for dividing large spaces into
smaller, private areas while ensuring superior sound insulation.
Efficient and Functional
Our banquet hall acoustic partition walls are part of a movable
soundproof partition system that forms a flexible and removable
wall. Utilizing an overhead track system, our partitions provide
smooth operation and excellent soundproofing. Perfect for hotels,
banquet halls, and other large venues, these partitions combine
flexibility with exceptional performance.
Roller Option & Feature
1. Dupont POM roller
2. 304 stainless steel heavy duty roller with safety device & CNC
machining
3. Unique and patented wheel surface and shape make the whole
movable partition easy to use
Panel Option & Feature
1. Thickness: 68mm & 89mm & 105mm
2. Wide variety of acoustical and decorative finishes available
3. 6061-T6 profile and inside Q235 steel frame for superior
durability
4 Top & bottom jack lifting mechanism seal are with power of 800N.
Magnetic seal in concave & convex profile has magnetic attraction
of 40N/m.
SPECIFICATION:
| GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS |
| | Dimensions in mm* | Design |
| Series | Element thickness | Element width* (min./max.) | Clear height* (min./max.) | Framed construction | Panel fixing | Element interconnection/design of
the vertical profiles |
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile
with magnetic strip
and sealing lips |
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in
Rw (dB):52/56
Positive and frictional locking of the vertical element
connections: Convex-concave profile form, force of attraction of
the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details
regarding the element heights/element
widths indicated can only be confirmed following consultation with
the Design Department.
** Depending on the sound insulation/weight |
