    Sinolift CDD12M CDD15M Walkie Electric Stacker

    Ask Lasest Price
    Brand Name : SINOLIFT
    Model Number : CDD12M CDD15M
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union
    Supply Ability : 1000 sets/mouth
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Sinolift CDD12M CDD15M Walkie Electric Stacker

    Sinolift CDD12M CDD15M Walkie Electric Stacker


    The Sinolift walk-behind electric stacker is a versatile and efficient material handling solution, ideal for small to medium-sized warehouses, factories, and supermarkets. Perfect for low-level stacking, it combines ease of use, steering, and maintenance with a compact design for excellent visibility and maneuverability. With a lifting capacity of 1200 to 1500 kg and a maximum lift height of 143 inches, this durable and cost-effective stacker is suited for a wide range of indoor applications. Its reliable performance enhances productivity and profitability, making it a valuable addition to any operation


    ModelCDD12CDD15
    PerformanceMaximum load capacitykg12001500
    with load center atQmm600600
    Weight (with battery)kg620620
    Maximum lifting heighth1mm30003000
    Travel speed (without load)km/h3.33.3
    Travel speed (with load)km/h3.23.2
    Lifting speed (without load)mm/s135135
    Lifting speed (with load)mm/s100100
    Lowered speed (without load)mm/s150150
    Lowered speed (with load)mm/s155155
    Ascend slope ability (without load )%55
    Ascend slope ability (with load )%33
    Overall length of frameLmm17401740
    DimensionsOverall width of frameBmm800800
    WheelbaseYmm12151215
    Fork lengthmm11501150
    Fork outside widthB1mm560/685560/685
    Fork inside widthB2mm240/365240/365
    Fork thicknessmm6060
    Min frounf heightmm3030
    Min intersecting aisle width 1000*1200mm22652265
    Fork lowered heightSmm8585
    Minimum turning radiusWamm14151415
    TireFront wheelmmØ80*70Ø80*70
    Drive wheelmm210*70210*70
    Caster wheelmm115*55115*55
    Wheel materialpolyurethane
    Electrical componentsDrive motor typeDC series motor
    Rated outputkw0.750.75
    Hoist motor typeDC series motor
    Rated outputkw2.22.2
    batteryVoltagV2424
    CapacityAH100100
    Weightkg35*235*2

    CDD12_13.jpgCDD12_01.jpgCDD12_02.jpgCDD12_03.jpgCDD12_04.jpgCDD12_05.jpgCDD12_06.jpgCDD12_07.jpgCDD12_08.jpgCDD12_09.jpgCDD12_10.jpgCDD12_11.jpgCDD12_12.jpg
