W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package

    Buy cheap W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package from wholesalers

    Buy cheap W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package from wholesalers
    • Buy cheap W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package from wholesalers

    W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package

    Ask Lasest Price
    Brand Name : Original Factory
    Model Number : W25Q80EWUXIE
    Certification : Lead free / RoHS Compliant
    Price : Contact for Sample
    Payment Terms : T/T
    Supply Ability : 10000 Pieces per Day
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package

    W25Q80EWUXIE Memory IC Chip 1.8V 8M-Bit Serial Flash Memory USON-8 Package


    Product Description Of W25Q80EWUXIE
    W25Q80EWUXIE (8M-bit) Serial Flash memory provides a storage solution for systems with limited space, pins and power. The 25Q series offers flexibility and performance well beyond ordinary Serial Flash devices. They are ideal for code shadowing to RAM, executing code directly from Dual/Quad SPI (XIP)
    and storing voice, text and data. The device operates on a single 1.65V to 1. 95V power supply with current consumption as low as 1mA active and 1μA for power-down. AlI devices are offered in space- saving packages.


    Specifications Of W25Q80EWUXIE

    8 Mbit

    1.65 V

    1.95 V

    20 mA

    SPI

    104 MHz

    1 M x 8

    8 bit

    Synchronous

    - 40 C

    + 85 C

    Unit Weight:

    719.231 mg


    Features Of W25Q80EWUXIE
    ●Family of SpiFlash Memories
    8M-bit/1M-byte (1 ,048 ,576)
    256-byte per programmable page
    Standard SPI: CLK, /CS, DI, DO, WP, /Hold
    Dual SPI: CLK, /CS, IOo, I01, /WP, /Hold
    Quad SPI: CLK, /CS, IOo, I01, IO2, IO3 ;
    QPI: CLK, /CS, IOo, IO1, IO2, IO3
    ●Highest Performance Serial Flash
    104MHz Dual/Quad SPI clocks
    208/416MHz equivalent Dual/Quad SPI
    50MB/S continuous data transfer rate
    Up to 6X that of ordinary Serial Flash
    Min 100K Program-Erase cycles per secton
    -More than 20-year data retention
    ●Low Power, Wide Temperature Range
    Single 1.65V to 1.95V supply
    1mA active current
    <1μA Power-down current
    -40°C to +85°C operating range
    ●Flexible Architecture with 4KB sectors
    Uniform Sector Erase (4K-bytes)
    Uniform Block Erase (32K and 64K-bytes)
    Program one to 256 bytes
    Erase/Program Suspend & Resume
    ●Advanced Security Features
    Software and Hardware Write-Protect
    Top/Bottom, 4KB complement array protection
    Lock-Down and Special OTP array protection
    64-Bit Unique Serial Number for each device
    Discoverable Parameters (SFDP) Register
    3X256-Byte Security Registers with OTP locks
    Volatile & Non-volatile Status Register Bits
