Product Description:
It utilizes advanced permanent magnet synchronous motor technology to deliver superior energy efficiency, precise speed
control, and ultra-low maintenance compared to traditional AC
induction or brushed motor fans.
Features:
Energy Efficiency
Low Noise Operation
Aesthetic and Functional Design
Adjustable Speed Control
Technical Parameters:
DIAMETER | 8ft(2.5m) | 12ft(3.8m) | 16ft(5.0m) | 20ft(6.2m) | 24ft(7.3m) |
MODEL | SFFCA25 | SFFCA38 | SFFCA50 | SFFCA62 | SFFCA73 |
AIR VOLUME | 6500m³/min | 8600m³/min | 13050m³/min | 14100m³/min | 15850m³/min |
MAXIMUM SPEED | 140RPM | 100RPM | 70RPM | 60RPM | 55RPM |
WEIGHT | 35Kg | 51Kg | 75Kg | 90Kg | 127Kg |
MOTOR POWER | 0.3kw | 0.4kw | 1.1kw | 1.1kw | 1.5kw |
FULL LOAD CURRENT | 1.8AMPS/220V | 2.0Amps/380v 2.3Amps/220v | 2.4Amps/380v 3.2Amps/220v | 3.0Amps/380v 3.5Amps/220v | 3.5Amps/380v 5.5Amps/220v |
Basic technical parameters: Model SFFCA73 (PMSM SERIES)
| No. | Main Configuration | Description | Photo |
| 1 | Motor | 1. High Quality PMSM motor; Power: 1.5kw; Insulation class: F,
50/60HZ; 2. Energy efficiency rating IE2; Operating noise less than 40dB; 3. No gear box, no oil change, truly maintenance-free; |  |
| 2 | Inverter | Built-in safety protection module, Control system: Built-in safety
protection module, automatically cut off the output in the event of
an accident. |  |
| 3 | Blades | Our blade is made of 6063T5 special high-strength aviation
magnesium-aluminum alloy material, which is extruded into one
piece. |  |
Applications:
Manufacturing Plants
Logistics Warehouses
Greenhouses
Sports Arenas
Storage Areas
Performance Venues
Food Processing
Support and Services:
Efficient R&D team, one-to-one customized service Professional
R&D and customized ventilation and cooling solutions.
Provide professional technical consultation and problem solving to
help users solve problems encountered during installation,
debugging or use.
Online support, telephone support or on-site technical support
(depending on the service agreement).
Packing and Shipping:
Product Packaging and Shipping for PMSM Series HVLS Industrial
Fans:
The PMSM Series HVLS Industrial Fans are carefully packaged to
ensure safe delivery to our customers. Each fan is securely wrapped
and placed in a sturdy wooden box with ample cushioning material to
prevent any damage during transit.
Equipment packaging:
Industrial large fans are packed in wooden cases, and a set of big
fans is composed of a square box and a long box.
FAQ:
Q: Are you factory or trading company?
A: We are factory which established more than 12 years.
Q: How is your motor’s quality compared with others?
A: High efficiency (85%~89%) is our strength.
Low repair rate (less than 0.08%).
All the motors have passed ISO9000, CE.
Q: Where is the HVLS Industrial Fan manufactured?
A: The fan is manufactured in Wuhan, China.
Q: Can you provide customized logo?
A: Yes, clients’ own logo or branding words can be customized on
the motor.
Q: What is the minimum order quantity for the HVLS Industrial Fan?
A: The minimum order quantity is 10 sets.
Q: What is your delivery time?
A: Usually we have stock, delivery time within 7 working days.
If there is customized requirement, time is negotiable.
Q: What other services can you provide?
A: Accepted delivery terms: FOB,CFR,CIF,EXW,DDP,DDU.
Accepted payment type: T/T, L/C;
