    The Whole Manual Sink Production Line Equipment

    Ask Lasest Price
    Brand Name : Star Power
    Model Number : YZ000-1
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100 Set/Sets per Month
    Delivery Time : 1 month
    • Product Details
    • Company Profile

    The Whole Manual Sink Production Line Equipment

    The Whole Manual Sink Production Line Equipment


    Product Introduction:

    • Strong customization: The manual sink production line has more advantages in processing fixed products, and only needs to adjust the equipment parameters to produce different specifications and shapes of the sink, without the need to customize expensive molds like the stretch sink production line.
    • High product quality: the thickness of the manual sink is basically the same, the welding process is advanced, the weld is fine treated, the appearance can hardly see the welding marks, the overall feeling is strong, the line sense is full. At the same time, the high degree of automation of the equipment can ensure the quality stability and consistency of the product.
    • High production efficiency: most of the equipment on the production line has realized automated or semi-automated operation, which greatly improves the production efficiency, reduces manual intervention, and reduces labor intensity.
    • Good cost control: Although the equipment investment of the manual sink production line is relatively high, due to its high production efficiency and good product quality, it can reduce production costs and improve the market competitiveness of the product.
    • Strong adaptability: The equipment of the entire production line can be flexibly configured and adjusted according to the needs of different customers to adapt to different scales and types of production.

    Product Parameters:

    Process termProcess introductionmachineMachine sizefloor spacepower(Kw)
    Length(m)Width(m)
    Process 1Steel Coil Laser cuttingLaser cutter line12000x2600x1950mm172.645
    Process 2Sheet welding for Saving MaterialStraight Seam Welding Machine1400x1100x2000mm1.41.10.4
    Process 3Sheet Grinding for Saving MaterialSheet Grinding Machine2250x1550x1800mm2.31.63.2
    Process 4Punching of water holeDeep throat Press machine/J21S-40T1500x1200x2000mm1.51.24
    Process 5Punching for PrebendingDeep throat press machine/J21S-63T1700x1400x2200mm1.71.44
    Process 6Press the water lineBending machine/30T-1600MM2600x1400x2000mm2.61.43
    Process 7Bending of the sink baseBending machine/63T-2500MM2800x1700x2350mm2.81.75.5
    Process 8Press arc & bottom cornerTwo-In-One Integrated Rolling Seam&Corner Pressing Machine1300x750x2000mm1.30.752.3
    Process 9Welding for vertical seams and bottom cornerCNC Welding Special Machine1400x1100x2000mm1.41.10.4
    Process 10Round corner Of vertical seams grinding (Inside)Grinding Machine For Round corner Of vertical seams2550x850x2200mm2.60.852.3
    Process 11Repair the Panel's missing cornersCNC Welding Special Machine(for panel repair)1100x850x1450mm1.10.850.4
    Process 12CNC Welding For Panel's Inner EdgeMulti-Axis CNC Welding Special Machine
    (For panel's inner edge)
    1700x1400x1600mm1.71.41.3
    Process 13Grinding for the sink's panelGrinding machine (Abrasive belt type)2500x1400x1700mm2.51.43
    Process 14Grinding for the sink's panel(mirror surface)Grinding machine3000x1400x1700mm31.43
    Process 15Painting For Sink Bottom Back SideManual painting equipment2200X1800X1600mm2.21.84.5
    Process 16Drying after PaintingDrying Oven13000X1000X1600mm13130
    Total floor space(Includ spaced distance and transportation route):>65m(Length)x 10m(Width)

    Detailed Photos:

    ​​


    Our Advantage:

    Foshan is a famous metal manufacturing city with mature and advanced machine technology and reasonable prices,We focus on providing kitchen supplies production solutions, including providing production machines, plant layout, production technology output, for you to save worry, labor and money, we wholeheartedly escort your career success.
