Slot Die Roll to Roll Coating Machine with One Oven for Lab Battery
R&D
Brief Introduction
This product is a high-precision coating equipment for continuous
and intermittent coating, which is convenient for surface coating
process of various substrates. Especially used in the lithium ion
battery industry, the equipment is designed to facilitate the use
of researchers, meet the requirements of coating accuracy and
consistency, and has excellent drying effect. It is an ideal choice
for the research and development of lithium ion batteries, super
capacitors, nickel batteries and other secondary batteries.
Features
● It can be switched freely to realize continuous and intermittent
coating.
● Tension control substrates and electrode material belt running
stability, also equipped with correction device.
● Hot air oven, blowing up and down, high quality drying effect.
● PLC control, touch screen operation, easy to use.
● Solvent recovery treatment unit is optional.
Technical Parameters
Model | STC-TMJ-300 |
Voltage | 3Phase AC380V, 50HZ |
Power | 15KW |
Coating method | Continuous coating;
Intermittent coating;
Tracking coating |
Roller width | 360mm |
Effective coating width | ≤300mm |
Running substrate thickness | Aluminum foil (Al): 11~30μm
Copper foil (Cu): 8~30μm |
| Coating speed | 0.3~0.5m/min, depends on drying conditions |
| Oven temperature | The max temperature is 150℃, the temperature difference in a single
oven is ≤ 5℃ |
| Oven length | 1m |
| Compressed air | The outlet pressure is more than 5.0kg/cm2 after drying, filtering and pressure stabilization. |
| Dimension | L1900 * W1100 * H1250mm |
| Weight | 1.2T |
Warranty
1 year's warranty with lifetime technical support.
FAQ
1. Are you a manufacture ?
A: Yes,our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab
research equipment. We owns a professional R&D department.
2. Do you accept customized product ?
A: Yes. Most of our products can be customized to meet different
requirments.
3. Will you provide test video before dispatch ?
A: Yes, we take test video for every equipment before dispatchm
which will display how to use it.
4. Can you offer overseas installation service ?
A: Yes, we can dispatch professional engineer for on-site
installion service.
