1th,product description
The WL-SY series is a very flexible shaped splicing processor. The
biggest feature of the product is that
it can freely capture any part of the input signal to a single LCD
unit through remote control .
The product supports 1 HDMI, 1 VGA, 1 USB, 1 VIDEO signal input,
and supports customized multiple
HDMI signal output. The input and output resolution up to
1920x1080@60HZ.
2th,Main functions
2.1, Grab an arbitrary image
The remote control can be used to zoom in on any part of the input
signal to the LCD screen display, as shown below:
2.2, Customizable multi-output on one machine
A single machine can customize multiple outputs, each output is
intercepted according to the arrangement
of the liquid crystal screen to display corresponding parts to the
corresponding liquid crystal unit to form
a personalized shaped mosaic, as shown below:
2.3, Multi-angle shaped stitching
Adding an arbitrary angle rotator to the front end of the WL-SY
profiled splicer can achieve multi-angle
rotation profile splicing, as shown in the following figure:
