Scalable NVMe PCIe SSDs PowerEdge R730XD U Rack Server

Name: Scalable NVMe PCIe SSDs PowerEdge R730XD U Rack Server
Brand: Dell Poweredge
Price: 1 USD

Ask Lasest Price
Model Number :	R730XD
Price :	Contact us
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Brand Name :	Dell Poweredge
Supply Ability :	/pieces >=2 pieces
Delivery Time :	2-7 working days

Add to Cart

Product Details
Company Profile

Scalable NVMe PCIe SSDs PowerEdge R730XD U Rack Server

PowerEdge R730xd

• Latest Intel Xeon E5-2600 v3
processors — up to 18 cores
• Up to 24 DIMMs DDR4 memory
• 6 distinct storage configurations
• Up to 6 PCIe 3.0 expansion slots
• Supports up to 4 Express Flash
NVMe PCIe SSDs
An exceptionally flexible and scalable, two-socket 2U rack server that delivers high-
performance processing and a broad range of workload-optimized local storage
possibilities, including hybrid tiering.

Designed with an incredible range of configurability, the
PowerEdge R730xd meets the needs of many different
workloads with the latest Intel® Xeon® processor
E5-2600 v3 product family, 24 DIMMs of high-performance
DDR4 memory and a broad range of local storage options.
Drive peak performance
Accelerate application performance with the latest
technologies and dynamic local storage. Scale quickly
and easily with front-accessible devices, ranging from
low-cost SATA hard drives to 1.8” ultra-fast, low-latency
PowerEdge Express Flash NVMe PCIe SSDs. Use hybrid
storage configurations to tailor the R730xd to your workload
needs and implement tiered-storage efficiencies. Combine
24-drive capacity with dual- PERC capability to drive storage
performance and take advantage of new Dell caching
technologies to boost application performance even more.
Discover greater versatility
Unlike previous PowerEdge servers, the R730xd can be
tailored for application performance by mixing high-speed
1.8” SSDs and low-cost, high-capacity 3.5” hard drives in
a single hybrid chassis, enabling accelerated data access
through in-server storage tiering.
• In its 24-drive, dual-PERC configuration, the R730xd
can be an excellent database server delivering more
than one million IOPS performance.
• Combine 26 drives with 24 DIMMs of memory and
six PCI Express® (PCIe) expansion slots to provide a
resource-rich virtualization environment.
• With up to four ultra-fast, ultra-low latency Express
Flash NVMe PCIe SSDs, the R730xd can boost
performance on critical workloads and share the cache
with other server.
• In its low-cost 16 x 3.5” drive configuration with
up to 100TB capacity, the R730xd is an excellent
Microsoft® SharePoint® and Exchange® server for
unified communications and collaboration (UC&C) and
delivers the scale-out storage efficiency demanded by
today’s XaaS providers, Hadoop/big data users and co-
location hosting.
Maximize operational efficiency
PowerEdge servers let you construct and manage highly
efficient infrastructures for data centers and small businesses.
Accelerate time-to-production with automated deployment
processes that use fewer manual steps and reduce human
error. Improve IT productivity in the data center with
innovative at-the-server management tools, like
iDRAC Quick Sync and iDRAC Direct to deliver in-depth
system health status and speed deployment. Optimize data
center energy usage with improved performance-per-watt
and more granular control of power and cooling.
Innovative management with
intelligent automation
The Dell OpenManage systems management portfolio
includes innovative solutions that simplify and automate
essential server lifecycle management tasks — making
IT operations more efficient and Dell servers the most
productive, reliable and cost effective. Leveraging the
incomparable agent-free capabilities of the PowerEdge
embedded integrated Dell Remote Access Controller
(iDRAC) with Lifecycle Controller technology, server
deployment, configuration and updates are streamlined
across the OpenManage portfolio and through integration
with third-party management solutions.
Monitoring and control of Dell and third-party data
center hardware is provided by OpenManage Essentials
and with anytime, anywhere mobile access, through
OpenManage Mobile. OpenManage Essentials also delivers
Server Configuration Management capabilities that
automate one-to-many PowerEdge bare-metal server
and OS deployments, quick and consistent replication of
configurations and ensure compliance to a predefined
baseline with automated drift detection.
PowerEdge R730xd
PowerEdge R730xd
• Latest Intel Xeon E5-2600 v3
processors — up to 18 cores
• Up to 24 DIMMs DDR4 memory
• 6 distinct storage configurations
• Up to 6 PCIe 3.0 expansion slots
• Supports up to 4 Express Flash
NVMe PCIe SSDs
An exceptionally flexible and scalable, two-socket 2U rack server that delivers high-
performance processing and a broad range of workload-optimized local storage
possibilities, including hybrid tiering.

Processor	Up to two 2nd Generation Intel庐 Xeon庐 Scalable processors, up to 28 cores per processor
Memory	24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB maxUp to 12 NVDIMM, 192 GB Max Up to 12 Intel® Optane™ DC persistent memory PMem, 6.14TB max (7.68TB max with PMem + LRDIMM)Supports registered ECC DDR4 DIMMs only
Storage controllers Internal Boot	Internal Controllers: PERC H330, H730P, H740P, HBA330, H750, HBA350i External Controllers: H840, HBA355e, 12 Gbps SAS HBASoftware RAID:S140Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB Internal Dual SD Module1
Storage	Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5” SAS/SATA HDD max 128TB Optional DVD-ROM, DVD+RW
Power supplies	Titanium 750W, Platinum 495W, 750W,750W 240VDC,2 1100W,1100W 380VDC2 1600W, 2000W and 2400W, Gold 1100W -48VDC Hot plug power supplies with full redundancyUp to 6 hot plugs fans with full redundancy
Dimensions	Form factor: Rack (2U)Height: 86.8mm (3.4”) Width3 : 434.0mm (17.08”)Depth3 : 737.5mm (29.03”) Weight: 28.6kg (63lbs.)
Embedded management	iDRAC9, iDRAC Direct, iDRAC RESTful with Redfish, Quick Sync 2 wireless module (optional)
Bezel	Optional LCD Bezel or Security bezel
OpenManage™ Software	OpenManage Enterprise OpenManage Mobile OpenManage Power Manager
I/O & Ports	Network daughter card options 4 x 1GbE or 2 x 10GbE + 2 x 1GbE or 4 x 10GbE or 2 x 25GbE Front ports: 1 x Dedicated iDRAC Direct Micro-USB, 2 x USB 2.0, 1 x USB 3.0 (optional), 1 x VGA Rear ports: 1 x Dedicated iDRAC network port, 1 x Serial, 2 x USB 3.0, 1 x VGA Video card: 2 x VGARiser options with up to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots
Other	Embedded NIC: 4 x 1GbE, 2x10+2GbE, 4 x 10GbE NDC Power Supplies: Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W AC power supply Availability: ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD module, single device data correction (SDDC), spare rank, tool-less chassis, support for high availability clustering and virtualization, proactive systems management alerts, iDRAC8 with Lifecycle Controller Remote Management: iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade) Systems Management: IPMI 2.0 compliant Dell OpenManage Essentials Dell OpenManage Mobile Dell OpenManage Power Center Dell OpenManage Integrations: OpenManage Integration for Microsoft® System Center OpenManage Integration for VMware® vCenter™ Dell OpenManage Connections: HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management OpenManage Plug-in for Oracle® Database Manager Rack Support: ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm. Operating System: Microsoft Windows Server® 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows HPC Server 2008 Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux® VMware ESX® Optional Embedded Hypervisors: Citrix® XenServer® VMware vSphere® ESXi™

Ready Stack is a program that is directed primarily toward channel partners and their
customers. The program enables them to easily build complete CI systems from
combinations of Dell EMC servers, storage, networking, data protection, and other
components. For networking, the use of Dell EMC open-standards-based networking
technologies is preferred but not required.
Ready Stacks are compatible with hypervisors from VMware and Microsoft and with
Microsoft operating systems. Ready Stacks can be managed by the Dell EMC portfolio of
management products and protected by Dell EMC data protection solutions.
The following figure illustrates the Ready Stack reference system.
Figure 1. Ready Stack reference system
A Ready Stack reference architecture specifies all the hardware, software, resources, and
services that are needed to run a scalable, highly available CI environment. This end-to-
end solution approach means that a system can be operational in a shorter time than is
typically possible with build-your-own solutions.
Designing, configuring, and running a production-ready CI involves multiple
considerations, including:
• Selection of operating system and virtualization software distributions
• Selection of monitoring and management software
• Allocation of cluster services and data storage to physical nodes and arrays
• Selection of server hardware
• Design of the network fabric
• Sizing and scalability
• Performance
Ready Stack
overview
