| Brand Name : | BTB |
| Certification : | CE CB UL FCC SAA GS ROHS CCC KC |
| Model Number : | B-001500200 |
| Price : | $1.0-$1.5 |
| Delivery Time : | 7-10days |
| Payment Terms : | T/T,L/C,Western union,Cash,Paypal |
| Supply Ability : | 200000pcs/week |
DC Output Type and Plug In Connection ac dc power supply 12v 2a power adapter
| Usage | * LED strip ,LED light ,LED table lamp. * Router,amplifier,CCTV camera, * Home appliances ,setup box ,speaker, * Audio & Video equipments, * Wireless communication electronics . * Medical equipments |
| DC Output Voltage | 12V± 5% |
| DC Output Current | 2000mA |
| DC Output Power | 24W |
| Working efficency | 78% |
| Adapter Size | 72*28*31mm (L/W/H) |
| Efficiency | level 5 |
| Warranty | 2years |
| Certificates approved | TUV CB CE GS ROHS UL/CUL FCC IECS SAA C-tick |
| Input Rated Voltage | 86Vac~264Vac |
| Input Frequency Range | 47Hz~63Hz |
| Safety protection | output voltage protection (120%-150% rated output current) |
| output current protection (150%-180% rated output current) | |
| short current protection | |
| Ripple and Noise | less than 60Mv at full road with 20MHz bandwidth |
| DC connector | 5.5*2.1*11mm (optional) |
| DC cable | 1.5m 2464UL 20AWG cable (optional) |
| Operating Temperature | 0°C - +55°C |
| Storage Temperature | -20°C - +85°C |
| Safety Standard | EN60950 EN60601 ESD (EN61000 3-3) |
| CAS (60950 ITE/TE,EN60601 Medical) FCC Part 15 subpart B Class 2 | |
| AN/NZS CISPR 22:2006 | |
| Turn On Delay Time | less than 3S (AC:110V and full load) |
| Dielectric Voltage | A IEC320 three pin input---output(FG)3000Vac one minute |
| Input Current | less than 0.5A |
| Input Inrush Current | less than 50A |
| Leakage Current | less than 5mA |
| Standby power | less than 0.1w |
| Net Weight | 116g/pcs |
| Gross Weight | 13.2kg/carton |
| Carton Box Size | 39*31*29cm |



Welcome to OEM/ODM
Free sample
Sample time : 3-5days
Delivery time:7-10days
Trade terms: FOB shenzhen
Payment : T/T ,L/C,PAYPAL ,Western Union
All product warranty 3 years(One years damage manufacture one to one exchange.)
Printing you LOGO and stick you modle also ok .
Credit is the basis , Quality is the first
Power adapter ,Charger ,Power supply Manufacture
Skype:beryl--qin
What's app: 86 13412619588
QQ:1767294269
Wechat: beryl18
www.btbadapter.com
|   |
