    Power supply 5V 250W 48v 30a switching power supply 10w switching power supply

    Ask Lasest Price
    Brand Name : BTB
    Model Number : BTB-150-12
    Certification : CE ,FCC ,CCC,Rohs,EMC,LVD
    Price : $3.0-10.00
    Supply Ability : 200000 Piece/Pieces per Week
    • Product Details
    • Company Profile

    Power supply 5V 250W 48v 30a switching power supply 10w switching power supply

    Power supply 5V 250W 48v 30a switching power supply 10w switching power supply


    SPECIFICATIONS
    S-250-12S-250-13.5S-250-15S-250-24S-250-27S-250-48
    12V13.5V15V24V27V48V
    ±1%±1%±1%±1%±1%±1%
    20A18.5A16.7A10A9A5A
    0-20A0-18.5A0-16.7A0-10A0-9A0-5A
    150mVp-p150mVp-p150mVp-p150mVp-p150mVp-p240mVp-p
    ±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
    ±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
    240W248W250.5W240W243W240W
    79%79.00%80.00%81%82%84%
    10~13.2V12~15V13.5~18V20~26.4V26~32V41~56V

    88~132VAC/176~264VAC selected by switch 47~63Hz;248~370VDC


    5A/115V 2.5A/230V
    <3.5mA/240VAC
    105%~135%
    Protection type: Fold back current limiting, recovers automatically after fault condition is removed.
    115%~135%
    Protection type: hiccup mode, recovers automatically after fault condition is removed.
    RT3≥55℃ Fan On, ≤45℃ Fan Off, ≥80℃ Output Shutdown (5~7.5V)
    RT3≥65℃ Fan On, ≤55℃ Fan Off, ≥80℃ Output Shutdown (12~15V)
    RT3≥70℃ Fan On, ≤60℃ Fan Off, ≥85℃ Output Shutdown (24~48V)
    -10℃~+50℃; 20%~90%RH
    -20℃~+85℃; 10%~95%RH
    10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes
    I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
    I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
    Design refer to UL1950
    Design refer to EN55022, EN55024, EN61000
    215*115*50mm(L*W*H)
    1Kg
    20pcs/20Kg

    1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.

    2. Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor.

    3.Tolerance: includes set up tolerance, line regulation and load regulation


    Product Description

    Welcome to OEM/ODM

    Free sample

    Sample time : 3-5days

    Delivery time:7-10days

    Trade terms: FOB shenzhen

    Payment : T/T ,L/C,PAYPAL ,Western Union

    All product warranty 3 years(One years damage manufacture one to one exchange.)

    Printing you LOGO and stick you modle also ok .


    Credit is the basis , Quality is the first

    Power adapter ,Charger ,Power supply Manufacture


    Phone : +86 13412619588

    Wechat:beryl18

    skype:beryl--qin


    www.btbadapter.com
