UNS S31653 / 316LN Stainless Steel Plate EN 1.4406 SS Plate
Products Specification
| Product name | 304H Stainless steel plate |
| Standard | GB,JIS,DIN,AISI,ASTM,AISI,ASME |
| Thickness | 3.0 - 20.0mm |
| Width | 1500mm, or as your requirements |
| Length | 3000,6000mm, or as your requirements |
| MOQ | 1MT |
| Surface | Hot rolled NO.1 Surface |
| Other Grade | 201 304 304L 309S 310S 316L 317L 316LN 321 347 329 409L 410 415 416
420 430 431 436L 439 440A/B/C 444 446 904L 2205 2507 254SMO 253MA
,1.4539,1.4828 Monel400 k500, Inconel 600,601,625,718, Incoloy 800 800H,C276.etc |
| Packing | standard export packing (inside:water proof paper,outside:steel
covered with strips and pallets) |
| Cargo ready date | within 25-35 days after confirming orders |
| Delivery Time | About 5-7 days after receive the deposit. |
316LN stainless steel plate introduction
316LN stainless steel is a low carbon, high nickel, high chromium
austenitic stainless steel with excellent corrosion resistance and
mechanical properties. It adds nitrogen on the basis of 316L
stainless steel to further improve strength and corrosion
resistance, especially for high-corrosion environments.
Main parameter
Chemical composition (typical value, %) :
- Carbon (C): ≤0.03
- Silicon (Si): ≤1.00
- Manganese (Mn): ≤2.00
- Phosphorus (P): ≤0.045
- Sulfur (S): ≤0.030
- Chromium (Cr): 16.0-18.0
- Nickel (Ni): 10.0-14.0
- Molybdenum (Mo): 2.0-3.0
- Nitrogen (N): 0.10-0.16
Mechanical properties of 316LN Stainless Steel Plate
- Tensile strength: ≥515 MPa
- Yield strength: ≥205 MPa
- Elongation: ≥40%
- Hardness: ≤217 HB
Physical properties of 316LN Stainless Steel Plate
- Density: 7.98 g/cm³
- Melting point: 1375-1400 °C
- Coefficient of thermal expansion: 16.5μm /m·°C (20-100 °C)
- Thermal conductivity: 16.3W /m·K (100 °C)
- Resistivity: 0.74 μΩ·m
Standard of 316LN Stainless Steel Plate
- ASTM: ASTM A240/A240M
- EN: EN 10088-2
- JIS: JIS G4304
- GB: GB/T 4237
Specification of 316LN Stainless Steel Plate
- Thickness: 0.5mm-100mm
- Width: 1000mm-2000mm
- Length: 2000mm-6000mm
- Surface treatment: 2B, BA, No.1, No.4, 8K, etc
Peculiarity of 316LN Stainless Steel Plate
- Corrosion resistance: Excellent performance in chloride and acidic
environments, especially suitable for seawater and chemical
environments.
- High strength: The addition of nitrogen increases strength and
hardness.
- Low temperature toughness: still maintains good toughness at low
temperatures.
- Machinability: Easy to weld, cut and form.
- Biocompatibility: Suitable for medical and food industries.
Apply of 316LN Stainless Steel Plate
- Chemical industry: Used to manufacture reactors, storage tanks,
pipelines, etc.
- Marine engineering: applicable to seawater desalination equipment,
ship components, etc.
- Nuclear industry: Used for nuclear reactor components.
- Medical equipment: for surgical instruments, implants, etc.
- Food processing: Used in food processing equipment and containers.
- Construction industry: Used for building structures in highly
corrosive environments.
316LN stainless steel plate with its excellent corrosion
resistance, high strength and good processing properties, widely
used in chemical, Marine, nuclear industry, medical and food
processing and other fields, is a typical representative of high
performance stainless steel.
