    3HHLM Low Sensitivity Gas Sensor for Methanol and Hydrogen Sulfide H2S Detection

    Ask Lasest Price
    Model Number : 3HHLM
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 3-5workingdays
    • Product Details
    • Company Profile

    3HHLM Low Sensitivity Gas Sensor for Methanol and Hydrogen Sulfide H2S Detection

    3HHLM Hydrogen Sulfide Sensor


    The 3HHLM CiTiceL is designed for use in applications where methanol might be present. Whilst cross
    sensitivity reactions on CiTiceLs are normally readily defined, the behavior of the 3HHLM when exposed to
    methanol is significantly more complex, and can not be specified as above for carbon monoxide. The 3HH/LM
    CiTiceL is the result of an extensive development project, which has achieved, for this application, a significant
    performance advantage over standard 3HH CiTiceLs


    CiTiceLs are designed for operation in a wide range of environments and harsh conditions. However, it is important
    that exposure to high concentrations of solvent vapours is avoided, both during storage, fitting into instruments
    and operation.
    When using sensors with printed circuit boards (PCBs), degreasing agents should be used before the sensor is
    fitted. Do not glue directly on or near the CiTiceL as the solvent may cause crazing of the plastic.


    Baseline Offset (clean air)*Baseline Offset (clean air)*
    Maximum Zero Shift0.1 ppm H2S equivalent
    Resolution0.1 ppm (when used with
    recommended electronics)
    Repeatability1% of signal
    Recommended Load Resistor10 Ω
