| Item | specification |
| OS | Linux |
| Language | Chinese/English/Russian/Others (can be customized) |
| Video Compression | H.265 H.264 |
| OSD | Character overlay function,Overlays information such as date time
and vehicle ID |
| GUI | Graphical User Interface | System parameters can be set through an external display screen and
remote control operation |
| Video Record System | Video Input | 4CH:1080P,720P,D1 8CH:1080P,720P,D1 |
| | Video Output | 1 composite video output+optional VGA output, 1.0Vp-p, 75 Ω,
supports 1 full screen and 2/4 split channels |
| | Preview | support Single channel, 2/4 screen splicing preview, support
manual/event triggered full screen display function |
| | Resolution | Maximum support: 4*1080P 25 frames per channel; 8*1080P 15 frames
per channel. |
| | Video Quality | 0-8 levels video recording available, 0 is the best level, 8 is the
lowest level. |
| | Video Standard | PAL: 100 frames per second, CCIR625 line, 50 fields NTSC: 120 frames per second, CCIR525 line, 60 fields; CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional; HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional; D1: 800Kbps ~ 3Mbps, multi levels video quality optional; 720P : 1Mbps~2Mbps, multi levels video quality optional; 1080P: 1Mbps~4Mbps, multi levels video quality optional; |
| | Record Mode | Default automatic recording, supporting ignition recording, manual
recording, alarm recording, etc |
| Audio | Audio Input | 4 or 8 channel aviation Plug |
| | Audio Output | 1channel |
| | Compression | G.711A compression, 8KB/s speed |
| Alarm Input | 4CH IO Alarm Input, pulse speed input,support alarm linkage
function |
| Alarm Output | 2-channel switch output, linked with sound and light alarm, oil and
power outage, etc | |
| Communication Interface | 1CH RS232,Expandable POS machine, fuel sensor, LED advertising
screen, OBD, etc | |
| 1CH 485 interface, can connect PTZ,etc. | |
| Wireless transfer | Built-in 4G network wireless transmission, TD-LTE, FDD-LTE | |
| Position | Support built-in GPS/BD module, can report to the CMSV7 standard
platform | |
| SD card | SD card | Support Two SD cards ,a maximum of 512G for a single card, can
support simultaneous video streaming to ensure data security | |
| Update Mode | Support USB flash drive upgrade, SD card upgrade, FTP remote
automatic upgrade | |
| Storage Mode | Exclusive bare disk storage method: Currently it is a relatively
advanced storage method in the industry | |
| USB | Front USB interface, can use USB flash disk to upgrade and backup ;
support USB mouse to backup video | |
| Video Playback | Video Search | Search video by Record Time/Record Mode etc | |
| Playback | Supports a maximum of four channels simultaneous replays, including
pause, fast forward, and fast rewind | |
| | Support x 2,x4,x8,x16. fast forward or fast backward play | |
| Voltage &Power Consumption | Power Management | Adaptive wide power input, with protection functions such as
overload, undervoltage, short circuit, and reverse connection; Support timed power on/off and delayed shutdown functions. | |
| Voltage Input | DC:+12V ~ +36V | |
| Voltage Output | +12V@2.5A,+5V@2A | |
| Power Consumption | Normal Working ＜5W | |
| Working Environment | Temperature | -20℃ to +70℃ | |
| Humidity | 20% to 80% | |
| Safety Management | Password Access | Two level management of user password and administrator password | |
| others | Size | 15CM (D)* 14.7CM(W)* 4CM(H) | |
| Net Weight | 0.7 Kg | |
