    85~260Vac 92% Conversion Efficiency RS485 Communication Electronic Load for AC Vehicle Inverter Burn-In Test Equipment

    AC Vehicle Inverter Charge And Discharge Burn-In Test Electronic Load


    Scope of application


    Independent burn-in trolley, Burn-in rack, Burn-in room
    Discharge burn-in test ofvarious AC output equipment (compatible with sine wave and square wave)
    Energy-saving and burn-in ofAC output of vehicle inverter

    Outstanding functions


    1. Independent load unit, supporting burn-in test of multiple groups of different output power supplies
    2. Use low-voltage power supply system to improve safety
    3. Over temperature protection, over current protection, over voltage protection, over power protection
    4. Up to 92% conversion efficiency
    5. High precision
    6. The output is connected in parallel to the DC power supply, which greatly reduces the power supply current required by the DC power supply
    7. Fully isolated RS485 communication
    8. Rugged shell structure and excellent heat dissipation system
    9. High quality and cost-effective
    10. Slowly adjust the power, it is not easy to make the customer's product current overcharge protection

    Performance parameters


    ModelCP8401CP8402CP8403CP8404
    Input voltage range85~260Vac85~260Vac90~280Vac260~530Vac
    Input current range0.5~6Adc0.5~10A0.5~32A0.5~32A
    Channel number4CH4CH1CH1CH
    Single channel power600W1600W7KW20KW
    Votage comtrol precision±2%+0.5%FS±2%+0.5%FS±2%+0.5%FS±2%+0.5%FS
    Voltage accuoacy±1%+0.5%FS±1%+0.5%FS±1%+0.5%FS±2%+0.5%FS
    Current control
    accuracy
    ±2%+0.5%FS±2%+0.5%FS±2%+0.5%FS±2%+0.5%FS
    Current readback
    accuracy
    ±1%+0.5%FS±1%+0.5%FS±1%+0.5%FS±1%+0.5%FS
    Output voltage10~48Vdc400Vdc50~750V50~750V
    Output current0~45Adc0~6Adc0~20A0~50A
    Pull-load modeCP,CCCP,CCCP,CCCP,CC
    Communication modeRS-485RS-485RS-485RS-485
