High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery

    Buy cheap High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery from wholesalers

    Buy cheap High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery from wholesalers
    • Buy cheap High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery from wholesalers
    • Buy cheap High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery from wholesalers

    High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery

    Ask Lasest Price
    Brand Name : HUATAO
    Model Number : HT
    Certification : CE, ISO, TUV
    Price : Negotiatable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 5000PCS/Per Month
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    High-Efficiency Reduction Bevel Gear Screw Jack with Grease Lubrication and Large Input Shaft for Industrial Machinery

    Bevel Gear Screw Jacks

    Bevel gear screw jacks are more efficient and faster than traditional worm-driven screw jacks, making them ideal for applications requiring quick and reliable lifting or positioning.

    Features of Bevel Gear Screw Jack


    ● High precision

    ● High-efficiency reduction

    ● Grease lubrication

    ● Lightweight housing

    ● Large input shaft

    Technical Data of Bevel Gear Screw Jacks
    ModelL-2.5TL-5TL-10TL-15TL-20TL-25T
    Max. Static Load ( KN )2550100150200250
    Lifting Screw ( mm )Tr30x6Tr40x7Tr58x12Tr58x12Tr65x12Tr90x16
    Gear Ratio-H1:11:11:11:11:11.5:1
    Travel length ( mm ) per turn of worm shaft-H6712121210.7
    Working Efficiency (%)-H262526262522
    Gear Ratio-L2:12:12:12:12:12.5:1
    Travel length ( mm ) per turn of worm shaft-L33.56666.4
    Working Efficiency (%)-H262526262522
    Max. Permissible stroke ( mm )150020002500250030003500
    Max. Stroke(mm) in Max. Compression load ( Unguided)200385400500600850
    Max. Stroke(mm) in Max. Compression load ( guided)400770800100012001700
    Max. Permissible torque(N.m) of worm shaftH:92 L:46H:232 L:116H:730 L:365H:1095 L:548H:1528 L:764H:2020 L:1212
    Weight without stroke ( Kg )4278112112148265
    Weight per 100mm screw and protective tube( Kg )0.450.821.681.682.14.15

    Main Application of Bevel Gear Screw Jacks

    • Crane
    • Stage
    • Paper
    • Non-ferrous metal
    • Food


    Packaging:

    FAQ:


    1. Can you customize it according to our requirements?
    We can design nonstandard products according to the customer's drawing and sample.


    2. What's your product range?
    speed reducer, gearbox, gear motor, pump, crusher


    3. What is the reason why we buy from you?
    With over 20 years of production experience and credibility. With a professional engineering team, advanced technology production, and skilled workers.Specialized in the production of reducer. Map sample processing business can be undertaken
