SAE J517 R2AT Hydraulic Hose

Name: SAE J517 R2AT Hydraulic Hose
Brand: Canka
Price: 1 USD

Add to Cart

CONSTRUCTION: This hose consists of an inner tube of oil syntheric rubber,two wires braid reinforcement,and an oil and weather resistant synthetic rubber cover.
APPLICATIONS: Hose range suitable to carry bydraulic fluids such as glycol,mineral oils、fuels、lubrication、emulsion、 hydrocarbons etc.
WORKING TEMPERATURE: From-40℃ up to +121℃
Nominal Diameter∮		Inside Diameter∮	Reinforcement Diameter∮	Outside Diameter∮	Working Pressure		Proof Pressure	Burst Pressure	Bend Radius
inch	dash	mm	mm	mm	bar	psi	bar	bar	mm
3/16	-3	4.6-5.4	10.6-11.7	13.3-14.1	350	5075	700	1400	100
1/4	-4	6.2-7.0	12.5-13.1	14.4-15.2	350	5075	700	1400	100
5/16	-5	7.7-8.5	14.2-14.8	16.3-17.1	297	4307	594	1188	115
3/8	-6	9.3-10.1	16.2-16.8	18.3-19.1	280	4060	560	1120	130
1/2	-8	12.3-13.5	19.4-20.0	21.5-22.3	245	3553	490	980	180
5/8	-10	15.5-16.7	22.8-23.4	25.0-25.8	192	2784	384	768	200
3/4	-12	18.6-19.8	26.4-27.2	28.6-29.4	157	2277	314	628	240
1	-16	25.0-26.4	33.9-34.7	36.3-37.1	140	2030	280	560	300
1-1/4	-20	31.4-33.0	42.8-43.6	45.3-46.1	113	1639	226	452	420
1-1/2	-24	37.7-39.3	49.2-50.0	51.7-52.5	87	1262	174	348	500
2	-32	50.4-52.0	61.9-62.7	64.4-65.2	78	1131	156	312	630
