SAE R1AT Hydraulic Hose

Name: SAE R1AT Hydraulic Hose
Brand: Canka
Price: 1 USD

Add to Cart

CONSTRUCTION: This hose consists of an inner tube of oil syntheric rubber,single wire braid reinforcement,and an oil and weather resistant synthetic rubber cover.
APPLICATIONS: Hose range suitable to carry bydraulic fluids such as glycol,mineral oils、fuels、lubrication、emulsion、 hydrocarbons etc.
WORKING TEMPERATURE: From-40℃ up to +121℃
Nominal Diameter∮		Inside Diameter∮	Reinforcement Diameter∮	Outside Diameter∮	Working Pressure		Proof Pressure	Burst Pressure	Bend Radius
inch	dash	mm	mm	mm	bar	psi	bar	bar	mm
3/16	-3	4.6-5.4	8.9-10.1	**	210	3045	420	840	89
1/4	-4	6.2-7.0	10.8-11.4	12.7-13.5	192	2784	384	768	102
5/16	-5	7.7-8.5	12.5-13.1	14.6-15.4	175	2538	350	700	114
3/8	-6	9.3-10.1	14.5-15.1	16.7-17.5	157	2277	314	628	127
1/2	-8	12.3-13.5	17.7-18.3	19.8-20.6	140	2030	280	560	178
5/8	-10	15.5-16.7	21.1-21.7	23.2-24.0	105	1523	210	420	203
3/4	-12	18.6-19.8	24.6-25.4	26.9-27.7	87	1262	174	348	241
1	-16	25.0-26.4	32.1-32.9	34.6-35.4	70	1015	140	280	305
1-1/4	-20	31.4-33.0	40.8-41.6	43.3-44.1	43	624	86	172	419
1-1/2	-24	37.7-39.3	47.2-48.0	49.7-50.5	35	508	70	140	508
2	-32	50.4-52.0	59.9-60.7	62.4-63.2	26	377	52	104	635
