Structural Ceramic parts / Blue Ceramic Block / Blue Ceramic Parts
for optical
TAG key words: structural ceramic parts , blue ceramic block , blue
ceramic parts
Produce and machining
We can produce different sizes and shapes of the Ceramic Block for specific applications to different custom products.Such as
drilling, polishing, stripes, concave and convex, screw holes,
metal parts position and so on
1. Can Be Custom By Drawing Or The Parameter
2.Can Be Offer a Samples Within 1--10 Qty
3. The Shipping Time Of The Samples Within 2days
4. Quick Delivery Via Fedex,Dhl,Ups,Tnt Etc.
For more informations (the price,payment etc), Please contact us or email: admin@cerampart.com
Application
Ceramic block can be used for a device or equipment in the special
environment such as Power isolation, high temperature protection,
durable wear, high and low temperature impact etc...and for the
different device should be requiry different ceramic block shapes,
like: some device need the round sheet be machining 8 hole to
fasten to the box.
Other type of ceramic sheet/ plate/ substrate/ piece/ blank
· Ttz: Magnesia Partially Stabilized Zirconia (Zro2) Sheet/ Plate/
· Ytzp: Yttria Partially Stabilized Zirconia (Zro2) Sheet/ Plate/
· Zdy: Yttria Fully Stabilized Zirconia (Zro2) Sheet/ Plate/
· Silicon Carbide Sheet/ Plate/
· Silicon Nitride Sheet/ Plate/
We can offer wide range temperature resisting Ceramic Block at 1200℃--2200℃. high temperature ceramic sheet made by advance
ceramics like:95%--99.99% Alumina(Al2O3), Zirconia(ZrO2) ,Silicon
Carbide,Silicon Nitride ...etc. The excellent high heat temperature
resistance for many industry.
Properties of Alumina and Zirconia Ceramic :
| Properties | Units | 95 Alumina | 99 Alumina | ZrO2 |
| Density | g / cm³ | 3.65 | 3.92 | 5.95-6.0g/cm³ |
| Water absorption | % | 0 | 0 | 0 |
| Coefficient of thermal expansion | 10-6/K | 7.9 | 8.5 | 10.5 |
| Modulus of Elasticity Young's Mod | GPa | 280 | 340 | 210 |
| Poisson's ratio | / | 0.21 | 0.22 | 0.3 |
| HV Hardness HV | MPa | 1400 | 1650 | 1300-1365 |
| Flexural Strength @ room temperature | MPa | 280 | 310 | 950 |
| Flexural Strength @700°C | MPa | 220 | 230 | 210 |
| Compressive Strength @ room temperature | MPa | 2000 | 2200 | 2000 |
| Fracture Toughness | MPa *m 1/2 | 3.8 | 4.2 | 10 |
| Heat conductivity @ room temperature | W/ m*k | 18-25 | 26-30 | 2-2.2 |
| Electrical Resistivity @ room temperature | Ω*mm2 /m | >1015 | >1016 | >1015 |
| Max use temperature | °C | 1500 | 1750 | 1050 |
| Resistance to acid alkaline | / | high | high | high |
| Dielectric Constant | / | 9.5 | 9.8 | 26 |
| Dielectric Strength | KV/mm | 16 | 22 | / |
| Thermol Shock Resistance | △ T ( °C ) | 220 | 180-200 | 280-350 |
| Tensile Strength @ 25 °C | MPa | 200 | 248 | 252 |
Specification Available:
| Wear-resistant Alumina Tile(Plain) |
| Item | (L)mm | (W)mm | (H)mm | Remarks |
| 60×60 | 60 | 60 | 10--25 | Plain & Weldable |
| 80×50 | 80 | 50 | 10--30 | Plain & Weldable |
| 90×60 | 90 | 60 | 10--30 | Plain & Weldable |
| 100×50 | 100 | 50 | 10--30 | Plain & Weldable |
| 100×80 | 100 | 80 | 10--30 | Plain & Weldable |
| 100×100 | 100 | 100 | 10--50 | Plain & Weldable |
| 120×80 | 120 | 80 | 10—50 | Plain & Weldable |
| 150×50 | 150 | 50 | 10--30 | Plain & Weldable |
| 150×100 | 150 | 100 | 10—50 | Plain & Weldable |
Blue Ceramic Plate / Blue Ceramic Block more photos:
Our High precision Machining Machine :
Laser Cutting machine making holes :
FAQ :
1. What kind of industry ceramics do you have ?
We specialized in 95% 97% 99% alumina ceramic and zirconia ceramic
parts .
2. What kind of molding method do can you supply ?
Dry Pressing , isostatic pressing , grouting , hot-chamber die
casting , tape casting , injection molding, etc, injection molding
and isostatic molding is the most commonly used.
3.What stabilizer do you use when processing ?
Yttria stabilizer is the most commonly used in our industrial
ceramic parts.
4.Can you produce free samples for me ?
Yes usually , we can produce free samples for you but it is up to
the product complexity .
5.What terms can you accept for payment ?
T/T, L/C , Western union , Money Gram and Paypal is welcome , but
paypal and western union only for small -sum payment.
