SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm

    Buy cheap SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm from wholesalers

    Buy cheap SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm from wholesalers
    • Buy cheap SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm from wholesalers
    • Buy cheap SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm from wholesalers

    SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm

    Ask Lasest Price
    Brand Name : Silian
    Model Number : Customized
    Certification : SGS/ ISO/RoHs
    Price : by case
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 20,000 pcs/month
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    SSP Monocrystal Sapphire Wafer Substrate 50mm 100mm 150mm 200mm

    SSP Substrate Single Side Polished Wafer 2inch/4inch/6inch/8inch


    Description


    Chemically, sapphire is single crystal aluminum oxide (Al2O3), and is useful in a transmission range from 0.2 - 5.5µm.Sapphire , so making them ideal materials for demanding applications (such as laser systems) because of their extreme surface hardness, high thermal conductivity, high dielectric constant and resistance to common chemical acids and alkalis. And sapphire also is the second hardest crystal next to diamonds and, because of their structural strength, sapphire windows can be made much thinner than other common dielectric windows with improved transmittance.


    Specification


    Size2inch4inch6inch8inch
    Material> 99.9996% Single Crystal Al203
    Crystal OrientationCustomized
    Diameter50.8+0.1mm100+0.1mm150+0.1mm200+0.1mm
    Thickness430um;650um; 720um;1000um; 1300um;1600um; 2000um;
    Flat LengthCustomized Flat/Notch
    TTV<5um<10um<15um<30um
    LTV<1.5um(5*5mm )<1.8um(5*5mm )<2um(10*10mm)<5um(15*15mm)
    BOW-8~0um-10~0um-10~4um-20~5um
    WARP< 10um< 18um< 30um< 40um
    Surface FinishRa<0.3nm
    Back Surface0.8-1.2um0.8-1.2um0.7-1.0um0.7-1.0um
    Wafer IDFront Side/ Back Side
    CleanlinessFree Visible Contamination
    PackageIn Cassettes Of 25
    OtherCustomized


    Process Flow
