High-Frequency Glove Packing Machine With Fully Automatic Degree Of
Automation
Product Description:
The surgical glove wallet type wrapping machine is a specialized
piece of equipment designed to package medical gloves for surgical
and examination use. It features a PLC and HMI control system, air
consumption of 7.5KW, and a power of 220V/50Hz 5KW, easy to operate
and low energy requirements. This machine is perfect for use in the
medical industry, as it is equipped with a number of innovative
features that make it efficient and reliable. It is equipped with
automatic paper feeding cutting wrapping folding, which makes it
easy to package gloves without manual intervention. The glove
packing machine is a great choice for those looking for an
efficient and reliable glove packaging solution, save in time and
labors.
 |  |  |
| Film roll holder is adjustable to meet requirements for different
folded sizes. | Reasonable glove module holder design, convinient for worker's
operation and tell left and right hand | Automatic paper feeding, cutting, filling and wrapping. |
 |  |  |
| Precise folding mechanism design ensures fast and good folding. | Large finished goods collection bin, big storage volume and keep
them squeeze exhaust for preparing of outer packing. | Wallet paper liner pack, easy for doctor's to open and wear without
outer pollutions. |
Features:
- Product Name: Glove Packing Machine
- Packing Size: L190*W95mm, to be customized
- Packing Material: 38-40g Single Shiny Medical Paper
- Capacity: 20-30 Bag/min
- Control System: PLC + HMI
- Advantage: Automatic Paper Feeding Cutting Wrapping Folding
- Glove Packaging Equipment
- Glove Wrapping Machine
- Glove Container Filling Machine
Technical Parameters:
| Attribute | Value |
|---|
| Advantage | Automatic Paper Feeding Cutting Wrapping Folding |
| Degree of automation | Fully Automatic |
| Size | 3100*3000*1800mm |
| Frequency | 50/60Hz |
| Air Consumption | 7.5 KW Air Compressor |
| Type | Surgical Glove Paper Liner Packing Machine |
| Air Pressure | 0.6MPa |
| Packing Size | L190*W95mm, to be customized |
| Power | 220V/50Hz 5 KW |
| Control System | PLC + HMI |
Applications:
Sayok's SN-100TK Glove Packaging Machine is designed to
automatically package surgical and examination gloves as wallets
for easy opening and wearing without outer pollutions. The machine
is fully automated and requires minimal operator intervention,
making it the perfect solution for hospitals, medical centers and
other medical institutions. With machine size is 3100*3000*1800mm
and weighs 1200kg, easy to move and small footprint, reasonable
design and layout the factory. It is output of 20-30 bag/min, very
high efficient to fulfil factory mill's requirements for daily
production, solve the problem of shortage of labors and cleaness
requirements.
Support and Services:
Glove Packing Machine Technical Support and Service
We provide technical support and service for the Glove Packing
Machine. Our experienced technicians are available to provide
advice and support on installation, maintenance and
troubleshooting.
We also offer a wide range of spare parts for the Glove Packing
Machine, such as conveyor belts, motors and sensors, as well as
consumables such as heat seal rolls and bags.
Our team of experienced engineers and technicians provide a
comprehensive service, from installation to maintenance, and are
available to answer any questions you may have.
We will strive to provide you with the best possible service and
support.
Packing and Shipping:
Packaging and Shipping for Glove Packing Machine
The Glove Packing Machine will be securely packaged to ensure that
it arrives in perfect condition. The machine will be packaged in
wooden exported case. The packaging will be specifically designed
to ensure the protection of the machine during transport.
