Sound Insulation Heat Preservation Corrosion Resistance Ceramic
Coated Aluminum Panel
Product Overview:
| Material | Aluminum | Aluminum Alloy | 1100 / 3003 / 5005 |
| Total Thickness | 2.0mm——4.5mm (normal), special thickness can be customized. | Surface Finish | Ceramic Coated |
| Class Fire Prevention | A1 | Warranty | 10-20 years |
| Size | 150~3000mm×150~6000mm, Special size can be customized. | Color | Customized |
| Packing | Wooden Box | MOQ | 500㎡ |
Product Information:
WHOLETOPS brand Sound Insulation Heat Preservation Corrosion Resistance Ceramic
Coated Aluminum Panel is composed of ceramic coated surface and aluminum plate. It is
mainly made of high quality aluminum alloy and formed by sheet
metal workshop through a variety of processing techniques. It is a
kind of decoration material for building interior and exterior
walls with superior performance. Its surface coating using advanced
ceramic coating system, which has excellent durability, chemical
corrosion resistance and good hardness and absolutely excellent
fire prevention, insulation performance.
Specification:
1. Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm,
7.0mm, 8.0mm and so on.
2. Surface finish: PVDF coated / Power coated
3. Aluminum Alloy: 1100, 3003, 5005
Scopes of Application:
Sound Insulation Heat Preservation Corrosion Resistance Ceramic
Coated Aluminum Panel is used for facade, fence, canopy, ceiling, screen, window, etc.
You can choose the patterns from our catalogue or send us the
drawing or picture, we can draw it for you.
Product advantages:
Fire-proofing: Grade A
Sound insulation: weight-counted sound insulation quantity 25dB
Thermal Insulation:Thermal conductivity 0.527W/m·K
Strong weather resistance:the material is self-cleaning. Using
rolling coating technology with 70% flurocarbon.
Minimum radius of arc slab is 300mm, its one-time process forming
no need second time process.ensure no damage to the panel strength.
Compare with PVDF coated solid aluminum panel:
| Item | PVDF coated | Ceramic paint |
| Fire proof grade | A2 grade(smoke) | A1 grade(no smoke) |
| Hardness | 0~2H | 7~9H |
| Scratch resistant | Easy to scratch | Not easy to scratch |
| High temperature resistant | 280℃ have smoke | 1600 ℃ no smoke |
| QBWear resistant standard | ＜500 time | ＞2000 time |
| Toxicity | Organic solvent | water |
| cleaning | not self-clean | Self - clean |
| life | 15 years | 30 years |
