Environmental Protection Energy-saving Ceramic Coated Aluminum
Panel
Product Overview:
| Material | Aluminum | Aluminum Alloy | 1100 / 3003 / 5005 |
| Total Thickness | 2.0mm——4.5mm (normal), special thickness can be customized. | Surface Finish | Ceramic Coated |
| Class Fire Prevention | A1 | Warranty | 10-20 years |
| Size | 150~3000mm×150~6000mm, Special size can be customized. | Color | Customized |
| Packing | Wooden Box | MOQ | 500㎡ |
Product Information:
WHOLETOPS brand Environmental Protection Energy-saving Ceramic Coated Aluminum
Panel is made of Aluminum alloy 1100 / 3003 / 5005 series (aluminum
sheet), As a kind of curtain wall, used for wall protection and
non-lighting walls, instead of mosaic and general sandblasting
facade. With its light texture, good strength characteristics in
the use of high-rise buildings have advantages, due to various
loads at high-rise buildings all the time, especially by the wind
pressure, mosaic Easy to fall off, because of the large wind
pressure and deformation. aluminum panel based on its unique
advantages and can be used in high building widely.
Specification:
1. Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm,
7.0mm, 8.0mm and so on.
2. Surface finish: PVDF coated / Power coated
3. Aluminum Alloy: 1100, 3003, 5005
Scopes of Application:
Interior or exterior wall panel for all public buildings such as
airport,railway station,hospital,shopping mall,etc.
All kinds of column cover and corner cladding.
Indoor ceiling for decoration.
Product advantages:
1. High hardness and scratch resistance; its hardness ≥ 7H, is 7
times compare with the fluorocarbon (PVDF) coated hardness
2. Silicate ceramic aluminum panel is use water as the solvent, not
including xylene, it is safe and green product
3. At 300 degree, the color will not change and coating will not
damaged. At 600 degrees, The coating film only occur discoloration
without decomposition, It belonging to the incombustible decorative
material, fire rating of A1 (fluorocarbon sheet A2)
4. Inorganic material to eliminate static electricity, so that the
pollutants in the atmosphere will not adhesion, always keep the
gorgeous appearance, It has the self-cleaning function
5. Can provide a variety of color, can adjust the brightness in a
certain range, to meet the different requirements for the color and
luster of buildings, to the designer to provide more vast space
Compare with PVDF coated solid aluminum panel:
| Item | PVDF coated | Ceramic paint |
| Fire proof grade | A2 grade(smoke) | A1 grade(no smoke) |
| Hardness | 0~2H | 7~9H |
| Scratch resistant | Easy to scratch | Not easy to scratch |
| High temperature resistant | 280℃ have smoke | 1600 ℃ no smoke |
| QBWear resistant standard | ＜500 time | ＞2000 time |
| Toxicity | Organic solvent | water |
| cleaning | not self-clean | Self - clean |
| life | 15 years | 30 years |
